Part Number | Flanged-AC-Inlets----Flanged-AC-Outlets |
Description: | NEMA UL / CSA, IEC 60309, IEC 60320, EUROPEAN SCHUKO, UNITED KINGDOM, AUSTRALIAN, INTERNATIONAL FLANGED AC POWER INLETS, FLANGED AC OUTLETS, SOCKETS. 15 AMPERE 125 VOLT-125 AMPERE 250 VOLT. IP20, IP44, IP55, IP67 RATED.
Notes: * Flanged inlets, flanged outlets for all countries of the world are individually listed below in related products. * Scroll down in related products to view and select flanged inlets, flanged outlets and product installation options. |
Approvals: | C(UL)US (NEMA Devices), C(UL)US & OVE (IEC 60309 Devices), UL/CSA (IEC 60320 Devices). International (VDE European Devices), Australian (Devices). |
Certifications: | REACH, RoHS (Specific Versions), CE MARK |
Standards: | NEMA, UL 498, CSA, IEC 60309, IEC 60320, CEE 7/7, CEE 7/4, CEE 7/5, BS 1363, AS/NZS |
Price & Avail: | Contact Sales Office for Price and Delivery: Quantity Discount Incentives Available - Majority of all Products are in Stock |
Scroll down to view
Related Products
Related Products
Related Products:
5278-SS
15A-125V NEMA 5-15P FLANGED PANEL MOUNT POWER INLET, IMPACT RESISTANT NYLON, SPECIFICATION GRADE. WHITE.
Notes:
* Weatherproof / dust proof applications use #5200-WC cover & #5200-WTC terminal shield or # 79480 WP Cover.
** NEMA Panel Mount Power Inlets with same mounting pattern listed below.
**NEMA 5-15P Inlet #5278-SS (15A-125V). Accepts NEMA 5-15R & NEMA 5-20R connectors.
**NEMA 5-20P Inlet #5378-SS (20A-125V). Accepts NEMA 5-20R connectors.
**NEMA 6-15P Inlet #5678-SS (15A-250V). Accepts NEMA 6-15R connectors & NEMA 6-20R connectors.
**NEMA 6-20P Inlet #5478-SS (20A-250V). Accepts NEMA 6-20R connectors.
**NEMA L5-15R LOCKING inlet #4716-SS (15A-125V). Accepts NEMA L5-15R Locking connectors.
**NEMA L6-15P LOCKING inlet #L615-FI (15A-250V). Accepts NEMA L6-15R Locking connectors.
View: High Power NEMA Locking 20A, 30A Power Inlets. NEMA Flanged Inlets & Outlets Guide
5279-SS
15A-125V NEMA 5-15R FLANGED PANEL MOUNT POWER OUTLET, SPECIFICATION GRADE. WHITE.
Notes:
* Weatherproof / dust proof applications use #5200-WSC cover & #5200-WTC terminal shield or # 79480 WP cover.
** NEMA Flanged Panel Mount Outlets with same mounting pattern listed below.
**NEMA 5-15R Outlet Part #5279-SS (15A-125V). Accepts NEMA 5-15P plugs.
**NEMA 5-20R Outlet Part #5379-SS (20A-125V). Accepts NEMA 5-20P & NEMA 5-15P plugs.
**NEMA 6-15R Outlet Part #5679-SS (15A-250V). Accepts NEMA 6-15P plugs.
**NEMA 6-20R Outlet Part #5479-SS (20A-250V). Accepts NEMA 6-20P & NEMA 6-15P plugs.
**NEMA L5-15R Locking Outlet #4715-SS (15A-125V). Accepts NEMA L5-15P Locking plugs.
**NEMA L6-15R Locking Outlet #L615-FO (15A-250V). Accepts NEMA L6-15P Locking plugs.
View: Optional panel mount designs # 5258-I, # 5258-QC (Quick Connect / Solder Terminals), # 70020 weather resistant.
70020-BLK-NS
15A-125V NEMA 5-15R WEATHERPROOF OUTLET, PANEL / WALL BOX MOUNT, TYPE B, IP54 RATED. BLACK.
Notes:
* American 2x4, 4x4 wall box mount applications = Use #97120-BZ, #97120-DBZ wall plates.
* Terminals, conductor cover for panel mount applications = Use #70127.
* Not for use with #70125 wall box.
View: Optional panel mount designs # 5279-SS, # 5258, # 5258-QC.
View: European, British, Australia, Universal Weatherproof outlets with same mounting design.
5378-SS
20A-125V NEMA 5-15P FLANGED PANEL MOUNT POWER INLET, IMPACT RESISTANT NYLON, SPECIFICATION GRADE. WHITE.
Notes:
* Weatherproof / dust proof applications use #5200-WC cover & #5200-WTC terminal shield or # 79480 WP Cover.
* Temp. range = -40°C to +75°C. Terminals accept 16AWG-10AWG. Max. torque = 11 in. lbs.
** NEMA Panel Mount Power Inlets with same mounting pattern listed below.
**NEMA 5-15P Inlet #5278-SS (15A-125V). Accepts NEMA 5-15R & NEMA 5-20R connectors.
**NEMA 5-20P Inlet #5378-SS (20A-125V). Accepts NEMA 5-20R connectors.
**NEMA 6-15P Inlet #5678-SS (15A-250V). Accepts NEMA 6-15R connectors & NEMA 6-20R connectors.
**NEMA 6-20P Inlet #5478-SS (20A-250V). Accepts NEMA 6-20R connectors.
**NEMA L5-15R LOCKING inlet #4716-SS (15A-125V). Accepts NEMA L5-15R Locking connectors.
**NEMA L6-15P LOCKING inlet #L615-FI (15A-250V). Accepts NEMA L6-15R Locking connectors.
View: High Power NEMA Locking 20A, 30A Power Inlets. NEMA Flanged Inlets & Outlets Guide
5379-SS
20A-125V NEMA 5-20R FLANGED PANEL MOUNT POWER OUTLET, SPECIFICATION GRADE. WHITE.
Notes:
* Weatherproof / dust proof applications use #5200-WSC cover & #5200-WTC terminal shield or # 79480 WP cover.
** NEMA Flanged Panel Mount Outlets with same mounting pattern listed below.
**NEMA 5-15R Outlet Part #5279-SS (15A-125V). Accepts NEMA 5-15P plugs.
**NEMA 5-20R Outlet Part #5379-SS (20A-125V). Accepts NEMA 5-20P & NEMA 5-15P plugs.
**NEMA 6-15R Outlet Part #5679-SS (15A-250V). Accepts NEMA 6-15P plugs.
**NEMA 6-20R Outlet Part #5479-SS (20A-250V). Accepts NEMA 6-20P & NEMA 6-15P plugs.
**NEMA L5-15R Locking Outlet #4715-SS (15A-125V). Accepts NEMA L5-15P Locking plugs.
**NEMA L6-15R Locking Outlet #L615-FO (15A-250V). Accepts NEMA L6-15P Locking plugs.
View: Optional panel mount designs # 5358-I, # 5358-QC (Quick Connect / Solder Terminals), # 70050-BLK weather resistant.
70050-BLK
20A-125V NEMA 5-20R WEATHERPROOF OUTLET, PANEL / WALL BOX MOUNT, TYPE B, IP44 RATED. BLACK.
Notes:
* American 2x4, 4x4 wall box mount applications = Use #97120-BZ, #97120-DBZ wall plates.
* Terminals, conductor cover for panel mount applications = Use #70127.
* Not for use with #70125 wall box.
View: Optional panel mount designs # 5379-SS, # 5358, # 5358-QC.
View: European, British, Australia, Universal Weatherproof outlets with same mounting design.
5678-SS
15A-250V NEMA 6-15P FLANGED PANEL MOUNT POWER INLET, IMPACT RESISTANT NYLON, SPECIFICATION GRADE. WHITE.
Notes:
* Weatherproof / dust proof applications use #5200-WC cover & #5200-WTC terminal shield or # 79480 WP Cover.
* Temp. range = -40°C to +75°C. Terminals accept 16AWG-10AWG. Max. torque = 11 in. lbs.
** NEMA Panel Mount Power Inlets with same mounting pattern listed below.
**NEMA 5-15P Inlet #5278-SS (15A-125V). Accepts NEMA 5-15R & NEMA 5-20R connectors.
**NEMA 5-20P Inlet #5378-SS (20A-125V). Accepts NEMA 5-20R connectors.
**NEMA 6-15P Inlet #5678-SS (15A-250V). Accepts NEMA 6-15R connectors & NEMA 6-20R connectors.
**NEMA 6-20P Inlet #5478-SS (20A-250V). Accepts NEMA 6-20R connectors.
**NEMA L5-15R LOCKING inlet #4716-SS (15A-125V). Accepts NEMA L5-15R Locking connectors.
**NEMA L6-15P LOCKING inlet #L615-FI (15A-250V). Accepts NEMA L6-15R Locking connectors.
View: High Power NEMA Locking 20A, 30A Power Inlets. NEMA Flanged Inlets & Outlets Guide
5679-SS
15A-250V NEMA 6-15R FLANGED PANEL MOUNT POWER OUTLET, IMPACT RESISTANT NYLON BODY, SPECIFICATION GRADE. WHITE.
Notes:
* Weatherproof / dust proof applications use #5200-WSC cover & #5200-WTC terminal shield or # 79480 WP cover.
** NEMA Flanged Panel Mount Outlets with same mounting pattern listed below.
**NEMA 5-15R Outlet Part #5279-SS (15A-125V). Accepts NEMA 5-15P plugs.
**NEMA 5-20R Outlet Part #5379-SS (20A-125V). Accepts NEMA 5-20P & NEMA 5-15P plugs.
**NEMA 6-15R Outlet Part #5679-SS (15A-250V). Accepts NEMA 6-15P plugs.
**NEMA 6-20R Outlet Part #5479-SS (20A-250V). Accepts NEMA 6-20P & NEMA 6-15P plugs.
**NEMA L5-15R Locking Outlet #4715-SS (15A-125V). Accepts NEMA L5-15P Locking plugs.
**NEMA L6-15R Locking Outlet #L615-FO (15A-250V). Accepts NEMA L6-15P Locking plugs.
View: Optional panel mount designs # 5658-I, # 5658-QC (Quick Connect / Solder Terminals).
5478-SS
20A-250V NEMA 6-20P FLANGED PANEL MOUNT POWER INLET, IMPACT RESISTANT NYLON, SPECIFICATION GRADE. WHITE.
Notes:
* Weatherproof / dust proof applications use #5200-WC cover & #5200-WTC terminal shield or # 79480 WP Cover.
* Temp. range = -40°C to +75°C. Terminals accept 16AWG-10AWG. Max. torque = 11 in. lbs.
** NEMA Panel Mount Power Inlets with same mounting pattern listed below.
**NEMA 5-15P Inlet #5278-SS (15A-125V). Accepts NEMA 5-15R & NEMA 5-20R connectors.
**NEMA 5-20P Inlet #5378-SS (20A-125V). Accepts NEMA 5-20R connectors.
**NEMA 6-15P Inlet #5678-SS (15A-250V). Accepts NEMA 6-15R connectors & NEMA 6-20R connectors.
**NEMA 6-20P Inlet #5478-SS (20A-250V). Accepts NEMA 6-20R connectors.
**NEMA L5-15R LOCKING inlet #4716-SS (15A-125V). Accepts NEMA L5-15R Locking connectors.
**NEMA L6-15P LOCKING inlet #L615-FI (15A-250V). Accepts NEMA L6-15R Locking connectors.
View: High Power NEMA Locking 20A, 30A Power Inlets. NEMA Flanged Inlets & Outlets Guide
* NEMA Plugs, Outlets, Power Cords, PDU Strips, Inlets, Outlets are listed below in related products. Scroll down to view.
5479-SS
20A-250V NEMA 6-20R FLANGED PANEL MOUNT POWER OUTLET, SPECIFICATION GRADE. WHITE.
Notes:
* Weatherproof / dust proof applications use #5200-WSC cover & #5200-WTC terminal shield or # 79480 WP cover.
** NEMA Flanged Panel Mount Outlets with same mounting pattern listed below.
**NEMA 5-15R Outlet Part #5279-SS (15A-125V). Accepts NEMA 5-15P plugs.
**NEMA 5-20R Outlet Part #5379-SS (20A-125V). Accepts NEMA 5-20P & NEMA 5-15P plugs.
**NEMA 6-15R Outlet Part #5679-SS (15A-250V). Accepts NEMA 6-15P plugs.
**NEMA 6-20R Outlet Part #5479-SS (20A-250V). Accepts NEMA 6-20P & NEMA 6-15P plugs.
**NEMA L5-15R Locking Outlet #4715-SS (15A-125V). Accepts NEMA L5-15P Locking plugs.
**NEMA L6-15R Locking Outlet #L615-FO (15A-250V). Accepts NEMA L6-15P Locking plugs.
View: Optional panel mount designs # 5858-QC (Quick Connect / Solder Terminals).
4716-SS
15A-125V NEMA L5-15P LOCKING FLANGED PANEL MOUNT POWER INLET, IMPACT RESISTANT NYLON, SPECIFICATION GRADE. WHITE.
Notes:
* Weatherproof / dust proof applications use #5200-WC cover & #5200-WTC terminal shield or # 79480 WP Cover.
* Temp. range = -40°C to +75°C. Terminals accept 16AWG-10AWG. Max. torque = 11 in. lbs.
** NEMA Panel Mount Power Inlets with same mounting pattern listed below.
**NEMA L5-15R LOCKING inlet #4716-SS (15A-125V). Accepts NEMA L5-15R Locking connectors.
**NEMA L6-15P LOCKING inlet #L615-FI (15A-250V). Accepts NEMA L6-15R Locking connectors.
**NEMA 5-15P Inlet #5278-SS (15A-125V). Accepts NEMA 5-15R & NEMA 5-20R connectors.
**NEMA 5-20P Inlet #5378-SS (20A-125V). Accepts NEMA 5-20R connectors.
**NEMA 6-15P Inlet #5678-SS (15A-250V). Accepts NEMA 6-15R connectors & NEMA 6-20R connectors.
**NEMA 6-20P Inlet #5478-SS (20A-250V). Accepts NEMA 6-20R connectors.
View: High Power NEMA Locking 20A, 30A Power Inlets. NEMA Flanged Inlets & Outlets Guide
4715-SS
15A-125V NEMA L5-15) FLANGED PANEL MOUNT POWER OUTLET, IMPACT RESISTANT NYLON BODY, SPECIFICATION GRADE. WHITE.
Notes:
* Weatherproof / dust proof applications use #5200-WSC cover & #5200-WTC terminal shield or # 79480 WP cover.
** NEMA Flanged Panel Mount Outlets with same mounting pattern listed below.
**NEMA L5-15R Locking Outlet #4715-SS (15A-125V). Accepts NEMA L5-15P Locking plugs.
**NEMA L6-15R Locking Outlet #L615-FO (15A-250V). Accepts NEMA L6-15P Locking plugs.
**NEMA 5-15R Outlet Part #5279-SS (15A-125V). Accepts NEMA 5-15P plugs.
**NEMA 5-20R Outlet Part #5379-SS (20A-125V). Accepts NEMA 5-20P & NEMA 5-15P plugs.
**NEMA 6-15R Outlet Part #5679-SS (15A-250V). Accepts NEMA 6-15P plugs.
**NEMA 6-20R Outlet Part #5479-SS (20A-250V). Accepts NEMA 6-20P & NEMA 6-15P plugs.
View: Optional panel mount design # 4710.
View: High Power NEMA Locking 20A, 30A Power Outlets. NEMA Flanged Outlets & Inlets Guide
L615-FI
15A-250V NEMA L6-15P LOCKING FLANGED PANEL MOUNT POWER INLET, IMPACT RESISTANT NYLON, SPECIFICATION GRADE. WHITE.
Notes:
* Weatherproof / dust proof applications use #5200-WC cover & #5200-WTC terminal shield or # 79480 WP Cover.
* Temp. range = -40°C to +75°C. Terminals accept 16AWG-10AWG. Max. torque = 11 in. lbs.
** NEMA Panel Mount Power Inlets with same mounting pattern listed below.
**NEMA 5-15P Inlet #5278-SS (15A-125V). Accepts NEMA 5-15R & NEMA 5-20R connectors.
**NEMA 5-20P Inlet #5378-SS (20A-125V). Accepts NEMA 5-20R connectors.
**NEMA 6-15P Inlet #5678-SS (15A-250V). Accepts NEMA 6-15R connectors & NEMA 6-20R connectors.
**NEMA 6-20P Inlet #5478-SS (20A-250V). Accepts NEMA 6-20R connectors.
**NEMA L5-15R LOCKING inlet #4716-SS (15A-125V). Accepts NEMA L5-15R Locking connectors.
**NEMA L6-15P LOCKING inlet #L615-FI (15A-250V). Accepts NEMA L6-15R Locking connectors.
View: High Power NEMA Locking 20A, 30A Power Inlets. NEMA Flanged Inlets & Outlets Guide
L615-FO
15A-250V NEMA L6-15R FLANGED PANEL MOUNT POWER OUTLET, IMPACT RESISTANT NYLON BODY, SPECIFICATION GRADE. WHITE.
Notes:
* Weatherproof / dust proof applications use #5200-WSC cover & #5200-WTC terminal shield or # 79480 WP cover.
* Temp. range = -40°C to +75°C. Terminals accept 16AWG-10AWG. Max. torque = 11 in. lbs.
** NEMA Flanged Panel Mount Outlets with same mounting pattern listed below.
**NEMA L5-15R Locking Outlet #4715-SS (15A-125V). Accepts NEMA L5-15P Locking plugs.
**NEMA L6-15R Locking Outlet #L615-FO (15A-250V). Accepts NEMA L6-15P Locking plugs.
**NEMA 5-15R Outlet Part #5279-SS (15A-125V). Accepts NEMA 5-15P plugs.
**NEMA 5-20R Outlet Part #5379-SS (20A-125V). Accepts NEMA 5-20P & NEMA 5-15P plugs.
**NEMA 6-15R Outlet Part #5679-SS (15A-250V). Accepts NEMA 6-15P plugs.
**NEMA 6-20R Outlet Part #5479-SS (20A-250V). Accepts NEMA 6-20P & NEMA 6-15P plugs.
View: Optional panel mount design # 4560.
View: High Power NEMA Locking 20A, 30A Power Outlets. NEMA Flanged Outlets & Inlets Guide
* Plugs, power cords, outlets, PDU strips, connectors, inlets, adapters are listed below in related products. Scroll down to view.
L520-FI
20A-125V NEMA L5-20P LOCKING FLANGED PANEL MOUNT POWER INLET, IMPACT RESISTANT NYLON BODY, SPECIFICATION GRADE. WHITE.
Notes:
* For weatherproof / dust proof applications use #5201-WC cover or #79485 cover.
* NEMA Panel Mount Power Inlets with same mounting design listed below.
**NEMA #L5-20FI Locking Inlet(20A-125V). Accepts Nema L5-20C Connectors.
**NEMA #L5-30FI Locking Inlet(30A-125V). Accepts Nema L5-30C Connectors.
**NEMA #L6-20FI Locking Inlet(20A-250V). Accepts Nema L6-20C Connectors.
**NEMA #L6-30FI Locking Inlet(30A-250V). Accepts Nema L6-30C Connectors.
View: High Power NEMA Locking 20A, 30A Power Inlets. NEMA Flanged Outlets & Inlets Guide
L520-FO
20A-125V NEMA L5-20R FLANGED PANEL MOUNT POWER OUTLET, IMPACT RESISTANT NYLON BODY, SPECIFICATION GRADE. WHITE.
Notes:
* For weatherproof / dust proof applications use #5203-WSC cover or #79485 cover.
** NEMA Flanged Panel Mount Outlets with same mounting pattern listed below.
**NEMA L5-20R Locking Outlet #L520-FO (20A-125V). Accepts NEMA L5-20P Locking plugs.
**NEMA L5-30R Locking Outlet #L530-FO (30A-125V). Accepts NEMA L5-30P Locking plugs.
**NEMA L6-20R Locking Outlet #L620-FO (20A-250V). Accepts NEMA L6-20P Locking plugs.
**NEMA L6-30R Locking Outlet #L630-FO (30A-250V). Accepts NEMA L6-30P Locking plugs.
View: Optional panel mount design # L520-R.
View: High Power NEMA Locking 20A, 30A Power Outlets. NEMA Flanged Outlets & Inlets Guide
L620-FI
20A-250V NEMA L6-20P LOCKING FLANGED PANEL MOUNT POWER INLET, IMPACT RESISTANT NYLON BODY, SPECIFICATION GRADE. WHITE.
Notes:
* For weatherproof / dust proof applications use #5201-WC cover or #79485 cover.
* NEMA Panel Mount Power Inlets with same mounting design listed below.
**NEMA #L5-20FI Locking Inlet(20A-125V). Accepts Nema L5-20C Connectors.
**NEMA #L5-30FI Locking Inlet(30A-125V). Accepts Nema L5-30C Connectors.
**NEMA #L6-20FI Locking Inlet(20A-250V). Accepts Nema L6-20C Connectors.
**NEMA #L6-30FI Locking Inlet(30A-250V). Accepts Nema L6-30C Connectors.
View: High Power NEMA Locking 20A, 30A Power Inlets. NEMA Flanged Outlets & Inlets Guide
L620-FO
20A-250V NEMA L6-20R FLANGED PANEL MOUNT POWER OUTLET, IMPACT RESISTANT NYLON BODY, SPECIFICATION GRADE. WHITE.
Notes:
* For weatherproof / dust proof applications use #5203-WSC cover or #79485 cover.
** NEMA Flanged Panel Mount Outlets with same mounting pattern listed below.
**NEMA L5-20R Locking Outlet #L520-FO (20A-125V). Accepts NEMA L5-20P Locking plugs.
**NEMA L5-30R Locking Outlet #L530-FO (30A-125V). Accepts NEMA L5-30P Locking plugs.
**NEMA L6-20R Locking Outlet #L620-FO (20A-250V). Accepts NEMA L6-20P Locking plugs.
**NEMA L6-30R Locking Outlet #L630-FO (30A-250V). Accepts NEMA L6-30P Locking plugs.
View: Optional panel mount design # L620-R.
View: High Power NEMA Locking 20A, 30A Power Outlets. NEMA Flanged Outlets & Inlets Guide
L530-FI
30A-125V NEMA L5-30P LOCKING FLANGED PANEL MOUNT POWER INLET, IMPACT RESISTANT NYLON BODY, SPECIFICATION GRADE. WHITE.
Notes:
* For weatherproof / dust proof applications use #5201-WC cover or #79485 cover.
* NEMA Panel Mount Power Inlets with same mounting design listed below.
**NEMA #L5-20FI Locking Inlet(20A-125V). Accepts Nema L5-20C Connectors.
**NEMA #L5-30FI Locking Inlet(30A-125V). Accepts Nema L5-30C Connectors.
**NEMA #L6-20FI Locking Inlet(20A-250V). Accepts Nema L6-20C Connectors.
**NEMA #L6-30FI Locking Inlet(30A-250V). Accepts Nema L6-30C Connectors.
View: High Power NEMA Locking 20A, 30A Power inlets. NEMA Flanged Outlets & Inlets Guide
L530-FO
30A-125V NEMA L5-30R FLANGED PANEL MOUNT POWER OUTLET, IMPACT RESISTANT NYLON BODY, SPECIFICATION GRADE. WHITE.
Notes:
* For weatherproof / dust proof applications use #5203-WSC cover or #79485 cover.
** NEMA Flanged Panel Mount Outlets with same mounting pattern listed below.
**NEMA L5-20R Locking Outlet #L520-FO (20A-125V). Accepts NEMA L5-20P Locking plugs.
**NEMA L5-30R Locking Outlet #L530-FO (30A-125V). Accepts NEMA L5-30P Locking plugs.
**NEMA L6-20R Locking Outlet #L620-FO (20A-250V). Accepts NEMA L6-20P Locking plugs.
**NEMA L6-30R Locking Outlet #L630-FO (30A-250V). Accepts NEMA L6-30P Locking plugs.
View: Optional panel mount design # L530-R.
View: High Power NEMA Locking 20A, 30A Power Outlets. NEMA Flanged Outlets & Inlets Guide
L630-FI
30A-250V NEMA L6-30P LOCKING FLANGED PANEL MOUNT POWER INLET, IMPACT RESISTANT NYLON BODY, SPECIFICATION GRADE. WHITE.
Notes:
* For weatherproof / dust proof applications use #5201-WC cover or #79485 cover.
* NEMA Panel Mount Power Inlets with same mounting design listed below.
**NEMA #L5-20FI Locking Inlet(20A-125V). Accepts Nema L5-20C Connectors.
**NEMA #L5-30FI Locking Inlet(30A-125V). Accepts Nema L5-30C Connectors.
**NEMA #L6-20FI Locking Inlet(20A-250V). Accepts Nema L6-20C Connectors.
**NEMA #L6-30FI Locking Inlet(30A-250V). Accepts Nema L6-30C Connectors.
View: High Power NEMA Locking 20A, 30A Power Inlets. NEMA Flanged Outlets & Inlets Guide
L630-FO
30A-250V NEMA L6-30R FLANGED PANEL MOUNT POWER OUTLET, IMPACT RESISTANT NYLON BODY, SPECIFICATION GRADE. WHITE.
Notes:
* For weatherproof / dust proof applications use #5203-WSC cover or #79485 cover.
** NEMA Flanged Panel Mount Outlets with same mounting pattern listed below.
**NEMA L5-20R Locking Outlet #L520-FO (20A-125V). Accepts NEMA L5-20P Locking plugs.
**NEMA L5-30R Locking Outlet #L530-FO (30A-125V). Accepts NEMA L5-30P Locking plugs.
**NEMA L6-20R Locking Outlet #L620-FO (20A-250V). Accepts NEMA L6-20P Locking plugs.
**NEMA L6-30R Locking Outlet #L630-FO (30A-250V). Accepts NEMA L6-30P Locking plugs.
View: Optional panel mount design # L630-R.
View: High Power NEMA Locking 20A, 30A Power Outlets. NEMA Flanged Outlets & Inlets Guide
L1420-FI
20A-125/250V NEMA L14-20P FLANGED PANEL MOUNT POWER INLET, SPECIFICATION GRADE. WHITE.
Notes:
* Weatherproof / dust proof applications use #5202-WC cover or #79485 cover.
View: Mating power connector # L1420-C.
View: High Power NEMA Locking 20A- 30A (4Pole / 5 Pole) Inlets & Outlets. NEMA Flanged Outlets & Inlets Guide
L1420-FO
20A-125/250V NEMA L14-20R FLANGED PANEL MOUNT POWER OUTLET, SPECIFICATION GRADE. WHITE.
Notes:
* Weatherproof / dust proof applications use #5205-WSC cover or #79485 cover.
View: Optional panel mount design # L1420-R.
View: High Power NEMA Locking 20A- 30A (4 Pole / 5 Pole) Outlets & Inlets. NEMA Flanged Outlets & Inlets Guide
L1430-FI
30A-125/250V NEMA L14-30P FLANGED PANEL MOUNT POWER INLET, IMPACT RESISTANT NYLON BODY, SPECIFICATION GRADE. WHITE.
Notes:
* Weatherproof / dust proof applications use #5202-WC cover or #79485 cover.
View: Mating power connector # L1430-C.
View: High Power NEMA Locking 20A- 30A (4Pole / 5 Pole) Inlets & Outlets. NEMA Flanged Outlets & Inlets Guide
L1430-FO
30A-250V NEMA L14-30R FLANGED PANEL MOUNT POWER OUTLET, IMPACT RESISTANT NYLON BODY, SPECIFICATION GRADE. WHITE.
Notes:
* Weatherproof / dust proof applications use #5205-WSC cover or #79485 cover.
View: Optional panel mount design # L1430-R.
View: High Power NEMA Locking 20A- 30A (4 Pole / 5 Pole) Outlets & Inlets. NEMA Flanged Outlets & Inlets Guide
L1520-FI
20 AMPERE-250 VOLT, 3 PHASE (X,Y,Z,+G) NEMA L15-20P LOCKING FLANGED PANEL MOUNT POWER INLET. WHITE.
Notes:
* Weatherproof / dust proof applications use #5202-WC cover or #79485 cover.
View: Mating power connector # L1520-C.
View: High Power NEMA Locking 20A- 30A (4Pole / 5 Pole) Inlets & Outlets. NEMA Flanged Outlets & Inlets Guide
L1520-FO
20 AMPERE-250 VOLT, 3 PHASE (X,Y,Z,+G) NEMA L15-20R LOCKING FLANGED PANEL MOUNT POWER OUTLET. WHITE.
Notes:
* Weatherproof / dust proof applications use #5205-WSC cover or #79485 cover.
View: Optional panel mount design # L1520-R.
View: High Power NEMA Locking 20A- 30A (4 Pole / 5 Pole) Outlets & Inlets. NEMA Flanged Outlets & Inlets Guide
L1530-FI
30 AMPERE-250 VOLT, 3 PHASE (X,Y,Z,+G) NEMA L15-30P LOCKING FLANGED PANEL MOUNT POWER INLET. WHITE.
Notes:
* Weatherproof / dust proof applications use #5202-WC cover or #79485 cover.
View: Mating power connector # L1530-C.
View: High Power NEMA Locking 20A- 30A (4Pole / 5 Pole) Inlets & Outlets. NEMA Flanged Outlets & Inlets Guide
L1530-FO
30 AMPERE-250 VOLT, 3 PHASE (X,Y,Z,+G) NEMA L15-30R LOCKING FLANGED PANEL MOUNT POWER OUTLET. WHITE.
Notes:
* Weatherproof / dust proof applications use #5205-WSC cover or #79485 cover.
View: Optional panel mount design # L1530-R.
View: High Power NEMA Locking 20A- 30A (4 Pole / 5 Pole) Outlets & Inlets. NEMA Flanged Outlets & Inlets Guide
L1620-FI
20 AMPERE-480 VOLT, 3 PHASE (X,Y,Z,+G) NEMA L16-20P LOCKING FLANGED PANEL MOUNT POWER INLET. WHITE.
Notes:
* Weatherproof / dust proof applications use #5202-WC cover or #79485 cover.
View: Mating power connector # L1620-C.
View: High Power NEMA Locking 20A- 30A (4Pole / 5 Pole) Inlets & Outlets. NEMA Flanged Outlets & Inlets Guide
L1620-FO
20 AMPERE-480, 3 PHASE (X,Y,Z,+G) NEMA L16-20R LOCKING FLANGED PANEL MOUNT POWER OUTLET. WHITE.
Notes:
* Weatherproof / dust proof applications use #5205-WSC cover or #79485 cover. < .
View: Optional panel mount design # L1620-R.
View: High Power NEMA Locking 20A- 30A (4 Pole / 5 Pole) Outlets & Inlets. NEMA Flanged Outlets & Inlets Guide
L1630-FI
30 AMPERE-480 VOLT, 3 PHASE (X,Y,Z,+G) NEMA L16-30P LOCKING FLANGED PANEL MOUNT POWER INLET. WHITE.
Notes:
* Weatherproof / dust proof applications use #5202-WC cover or #79485 cover.
View: Mating power connector # L1630-C.
View: High Power NEMA Locking 20A- 30A (4Pole / 5 Pole) Inlets & Outlets. NEMA Flanged Outlets & Inlets Guide
L1630-FO
30 AMPERE-480, 3 PHASE (X,Y,Z,+G) NEMA L16-30R LOCKING FLANGED PANEL MOUNT POWER OUTLET, 3 POLE-4 WIRE GROUNDING (3P+E), IMPACT RESISTANT NYLON BODY, SPECIFICATION GRADE. WHITE.
Notes:
* Weatherproof / dust proof applications use #5205-WSC cover or #79485 cover.
View: Optional panel mount design # L1630-R.
View: High Power NEMA Locking 20A- 30A (4 Pole / 5 Pole) Outlets & Inlets. NEMA Flanged Outlets & Inlets Guide
L2120-FI
20A-120/208V AC, 3 PHASE Y, NEMA L21-20P LOCKING FLANGED INLET, IMPACT RESISTANT NYLON BODY. WHITE.
Notes:
* For weatherproof / dustproof panel mount applications use #5202-WC inlet cover.
L2120-FO
20A-120/208V AC, 3 PHASE Y, NEMA L21-20FO LOCKING FLANGED OUTLET, IMPACT RESISTANT NYLON BODY. WHITE.
L2130-FI
30A-120/208V AC, 3 PHASE Y, NEMA L21-30P LOCKING FLANGED INLET, IMPACT RESISTANT NYLON BODY. WHITE.
Notes:
* For weatherproof / dustproof panel mount applications use #5202-WC inlet cover.
L2130-FO
30A-120/208V AC, 3 PHASE Y, NEMA L21-30FO LOCKING FLANGED OUTLET, IMPACT RESISTANT NYLON BODY. WHITE.
L2220-FI
20A-277/480V AC, 3 PHASE Y, NEMA L22-20P LOCKING FLANGED INLET, IMPACT RESISTANT NYLON BODY. WHITE.
Notes:
* For weatherproof / dustproof panel mount applications use #5202-WC inlet cover.
L2220-FO
20A-277/480V AC, 3 PHASE Y, NEMA L22-20FO LOCKING FLANGED OUTLET, IMPACT RESISTANT NYLON BODY. WHITE.
L2230-FI
30A-277/480V AC, 3 PHASE Y, NEMA L22-30P LOCKING FLANGED INLET, IMPACT RESISTANT NYLON BODY. WHITE.
Notes:
* For weatherproof / dustproof panel mount applications use #5202-WC inlet cover.
L2230-FO
30A-277/480V AC, 3 PHASE Y, NEMA L22-30FO LOCKING FLANGED OUTLET, IMPACT RESISTANT NYLON BODY. WHITE.
999-6134-NS
IEC 60309 (4h) PIN & SLEEVE PANEL MOUNT FLANGED INLET, 16A 110-130V (2P+E), SPLASHPROOF (IP44). 56mmX56mm C TO C MOUNTING. YELLOW. EUROPEAN OVE APPROVAL.
PIN AND SLEEVE IEC 60309 BROCHURE.
999-1216-NS
IEC 60309 (4h) PIN & SLEEVE PANEL MOUNT ANGLED RECEPTACLE OUTLET, 16A 110-130V (2P+E), SPLASHPROOF (IP44), 60mmX73mm C TO C MOUNTING. YELLOW. EUROPEAN OVE APPROVAL. PIN AND SLEEVE IEC 60309 BROCHURE.
888-6134-NS
IEC 60309 (4h) PIN & SLEEVE PANEL MOUNT FLANGED INLET, 20A-120V (2P+E), SPLASHPROOF (IP44). 56mmX56mm C TO C MOUNTING. YELLOW. C(UL)US APPROVED. PIN AND SLEEVE IEC 60309 BROCHURE.
888-1216-NS
IEC 60309 (4h) PIN & SLEEVE PANEL MOUNT ANGLED RECEPTACLE OUTLET, 20A-120V (2P+E), SPLASHPROOF (IP44), 60mmX73mm C TO C MOUNTING. YELLOW. C(UL)US APPROVED. PIN AND SLEEVE IEC 60309 BROCHURE.
888-6234-NS
IEC 60309 (4h) PIN & SLEEVE PANEL MOUNT FLANGED INLET, 30A-120V (2P+E), SPLASHPROOF (IP44). 56mmX56mm C TO C MOUNTING. YELLOW. C(UL)US APPROVED. PIN AND SLEEVE IEC 60309 BROCHURE.
888-1228-NS
IEC 60309 (4h) PIN & SLEEVE PANEL MOUNT ANGLED RECEPTACLE OUTLET, 30A-120V (2P+E), SPLASHPROOF (IP44). 60mmX73mm C TO C MOUNTING. YELLOW. C(UL)US APPROVED. PIN AND SLEEVE IEC 60309 BROCHURE.
888-6136-NS
IEC 60309 (6h) PIN & SLEEVE STRAIGHT POWER INLET, 20A/16A-220/250V (2P+E), SPLASHPROOF (IP44), CEE 17, IEC 309. C(UL)US LISTED & EUROPEAN OVE (UNIVERSAL APPROVALS). 56mmX56mm C TO C MOUNTING. BLUE. PIN AND SLEEVE IEC 60309 BROCHURE.
999-1154210
IEC 60309 (6h), 16A-250V, FLUSH MOUNT POWER INLET, SPLASHPROOF (IP44), 2 POLE-3 WIRE GROUNDING (2P+E). BEIGE. EUROPEAN APPROVALS.
Notes:
* Applications = European / International exported equipment, mobile units, RV, caravans, trailers, vans.
* Mating in-line connector #888-3126-NS.
888-1217-NS
IEC 60309 (6h) PIN & SLEEVE ANGLED RECEPTACLE OUTLET, 20A/16A-220/250V (2P+E), SPLASHPROOF (IP44), CEE 17, IEC 309. C(UL)US LISTED & EUROPEAN OVE (UNIVERSAL APPROVALS). 60mmX73mm C TO C MOUNTING. BLUE. PIN AND SLEEVE IEC 60309 BROCHURE.
888-6236-NS
IEC 60309 (6h) 30A-250V C(UL)US, 32A-220V OVE, SPLASHPROOF (IP44) PANEL MOUNT POWER INLET, UNIVERSAL APPROVALS, 56mmX56mm C TO C MOUNTING,BLUE. PIN AND SLEEVE IEC 60309 BROCHURE.
888-1229-NS
IEC 60309 (6h) 30A/32A-220/250V (2P+E) SPLASHPROOF (IP44) ANGLED PANEL MOUNT OUTLET, UNIVERSAL APPROVALS, 73.5mmX60mm C TO C MOUNTING. BLUE. PIN AND SLEEVE IEC 60309 BROCHURE.
888-7156-NS
IEC 60309 (6h) PIN & SLEEVE 3 PHASE PANEL MOUNT INLET, 20A-200/415V C(UL)US, 16A-220/380V - 240/415V OVE, (3P+N+E) SPLASHPROOF (IP44) UNIVERSAL, 56mmX56mm C TO C MOUNTING. RED. PIN AND SLEEVE IEC 60309 BROCHURE.
888-1227-NS
IEC 60309 (6h) PIN & SLEEVE 3 PHASE ANGLED PANEL MOUNT RECEPTACLE OUTLET, 20A-200/415V C(UL)US, 16A-220/380V - 240/415V OVE, (3P+N+E) SPLASHPROOF (IP44) UNIVERSAL ANGLED PANEL MOUNT OUTLET, 73.5mmX60mm C TO C MOUNTING. RED. PIN AND SLEEVE IEC 60309 BROCHURE.
888-6256-NS
IEC 60309 (6h) 3 PHASE INLET, 30A-200/415V C(UL)US, 32A-220/380V, 240/415V OVE, (3P+N+E) SPLASHPROOF (IP44) UNIVERSAL PANEL MOUNT INLET, 56mmX56mm C TO C MOUNTING. RED. PIN AND SLEEVE IEC 60309 BROCHURE.
888-1239-NS
IEC 60309 (6h) 3 PHASE OUTLET, 30A-200/415V C(UL)US, 32A-220/380V - 240/415V OVE, (3P+N+E) SPLASHPROOF (IP44) UNIVERSAL ANGLED PANEL MOUNT OUTLET. RED. NOTE: 73.5mmX60mm C TO C MOUNTING. PIN AND SLEEVE IEC 60309 BROCHURE.
888-661306
IEC 60309 (6h) 60A/63A-250V (2P+E) SPLASHPROOF (IP44) DOWN ANGLE POWER INLET, UNIVERSAL APPROVALS, 90mmX90mm C TO C MOUNTING. BLUE. PIN AND SLEEVE IEC 60309 BROCHURE.
888-560306
IEC 60309 (6h) 60A/63A-250V (2P+E) SPLASHPROOF (IP44) ANGLED PANEL/SURFACE MOUNT OUTLET, UNIVERSAL APPROVALS, 77mmX85mm C TO C MOUNTING. BLUE. PIN AND SLEEVE IEC 60309 BROCHURE.
888-665
IEC 60309 (6h) 3 PHASE INLET, 60A-380/415V (400 VOLT), 63A-220/380V - 240/415V (400 V0LT) EUROPEAN (3P+N+E), WATERTIGHT (IP67) & SPLASHPROOF (IP44) FLANGED POWER INLET, UNIVERSAL APPROVALS, 90mmX90mm C TO C MOUNTING. RED. PIN AND SLEEVE IEC 60309 BROCHURE.
888-129
IEC 60309 (6h) 3 PHASE OUTLET, 60A-380/415V (400 VOLT) UL/CSA, 63A-220/380V - 240/415V (400 V0LT) EUROPEAN (3P+N+E), WATERTIGHT (IP67) ANGLED FLANGED OUTLET, UNIVERSAL APPROVALS, 77mmX85mm C TO C MOUNTING. RED. PIN AND SLEEVE IEC 60309 BROCHURE.
888-679
IEC 60309 (6h) 3 PHASE INLET, 100A-380/415V (400 VOLT) UL/CSA, 125A-220/380V-240/415V (400 V0LT) EUROPEAN (3P+N+E), WATERTIGHT (IP67) POWER INLET, UNIVERSAL APPROVALS, 104mmX104mm C TO C MOUNTING. RED. PIN AND SLEEVE IEC 60309 BROCHURE.
888-12108
IEC 60309 (6h) 3 PHASE OUTLET, 100A-380/415V (400 VOLT) UL/CSA, 125A-220/380V - 240/415V (400 V0LT) EUROPEAN (3P+N+E), WATERTIGHT (IP67) ANGLED OUTLET, UNIVERSAL APPROVALS, 90mmX90mm C TO C MOUNTING. RED. PIN AND SLEEVE IEC 60309 BROCHURE.
70310-NS
EUROPEAN SCHUKO LOCKING 16A-250V CEE 7/3 (EU1-16R) TYPE F, IP66 / IP68 WATERTIGHT OUTLET (WITH GASKET), PANEL OR BOX MOUNT. BLUE.
Notes:
* # 70310-NS Outlet locks onto Watertight Plug # 70341-N . Prevents accidental disconnects.
* # 70310-NS Outlet locks onto Watertight Plug # 71441. Prevents accidental disconnects.
* European Schuko Watertight Extension cords available. View # 70025.
* Surface mount applications = Use # 71325,71320,71322 wall boxes listed below in related products.
* Available in Color Dark Green. Part #70310-NS-GRN
70300
EUROPEAN SCHUKO LOCKING 16A-250V CEE 7/3 (EU1-16R) TYPE F, IP66 / IP68 WATERTIGHT OUTLET, PANEL OR WALL BOX MOUNT (WITH GASKET), 2 POLE-3 WIRE GROUNDING (2P+E). BLUE.
Notes:
* # 70300 Outlet locks onto Watertight Plug # 70341-N . Prevents accidental disconnects.
* # 70300 Outlet locks onto Watertight Plug # 71441. Prevents accidental disconnects.
* # 70025 Watertight Extension cords available. View # 70025.
* Available in Color Dark Green. Part #70300-GRN
70190
EUROPEAN CEE 7/7 (EU1-16P) SCHUKO TYPE E, F, 16A-250V WEATHERPROOF IP44 POWER INLET. BLACK.
Notes:
* # 70190 Accepts European Schuko # 70161 (EU1-16R), France / Belgium # 71161 (FR1-16R) type connectors.
* IP68 Rated Watertight option listed below.
* # 71442 , 71443 , 71444 Watertight Power Inlets Lock onto Schuko Connector # 71445 . Prevents accidental disconnects.
70395
EUROPEAN SCHUKO 16 AMPERE 220-250 VOLT, 50/60 Hz, IP68 WATERTIGHT LOCKING FLANGE MOUNT (60mm-60mm) POWER INLET WITH GASKET AND CLOSURE COVER, CEE 7/4 TYPE E (EU1-16P), PANEL MOUNT OR WALL BOX MOUNT, 2 POLE-3 WIRE GROUNDING (2P+E). NYLON. GRAY / BLUE.
Notes:
* 70395 Watertight Power Inlet Locks onto Schuko Connector # 70361 . Prevents accidental disconnects.
* Material = Thermoplastic Elastomer, Temperature Range: -15°C to +70°C.
* European Schuko Watertight Extension cords available. View # 70025.
70120-LFL-WHT
EUROPEAN SCHUKO 16A-250V CEE 7/3 TYPE F OUTLET (EU1-16R), 50mmX50mm SIZE, PANEL OR WALL BOX MOUNT. WHITE.
Notes:
* Stainless steel wall plates #97120-BZ and #97120-DBZ mounts outlet onto standard American 2x4 and 4x4 wall boxes.
* Optional panel mount terminal shield #70127 available.
* European Schuko "locking" outlet #70300 available. Prevents accidental disconnects.
70120
EUROPEAN SCHUKO CEE 7/3 TYPE F (EU1-16R) 16A-250V WEATHERPROOF IP54 POWER OUTLET, PANEL OR WALL BOX MOUNT. GRAY FLIP LID, GRAY BASE.
Notes:
* Stainless steel wall plates #97120-BZ and #97120-DBZ mounts outlet onto standard American 2x4 and 4x4 wall boxes.
* For surface mount use #70125 wall box.
* For DIN rail mount use #70125-DIN bracket with #70125 wall box.
* Optional panel mount terminal shield #70127 available.
* European Schuko "locking" outlet #70300 available. Prevents accidental disconnects.
70120-BLK
EUROPEAN SCHUKO CEE 7/3 TYPE F (EU1-16R) 16A-250V WEATHERPROOF IP54 POWER OUTLET, PANEL OR WALL BOX MOUNT. BLACK.
Notes:
* Stainless steel wall plates #97120-BZ and #97120-DBZ mounts outlet onto standard American 2x4 and 4x4 wall boxes.
* For surface mount use #70125 wall box.
* For DIN rail mount use #70125-DIN bracket with #70125 wall box.
* Optional panel mount terminal shield #70127 available.
* European Schuko "locking" outlet #70300 available. Prevents accidental disconnects.
70120-BLK-GC
EUROPEAN SCHUKO CEE 7/3 TYPE F (EU1-16R) 16A-250V WEATHERPROOF IP54 POWER OUTLET, PANEL OR WALL BOX MOUNT. BLACK BASE, GRAY FLIP LID COVER.
Notes:
* Stainless steel wall plates #97120-BZ and #97120-DBZ mounts outlet onto standard American 2x4 and 4x4 wall boxes.
* For surface mount use #70125 wall box.
* For DIN rail mount use #70125-DIN bracket with #70125 wall box.
* Optional panel mount terminal shield #70127 available.
* European Schuko "locking" outlet #70300 available. Prevents accidental disconnects.
71125
FRANCE / BELGIUM LOCKING 16A-250V CEE 7/5 (FR1-16R) CEE 7/5 TYPE E IP66 / IP68 WATERTIGHT OUTLET (WITH GASKET), PANEL OR WALL BOX MOUNT. BLUE.
Notes:
* # 71125 Watertight Socket Locks onto France / Belgium Plug # 71341 # 71341. Prevents accidental disconnects.
* # 71125 Watertight Socket Locks onto Schuko Plug # 70341-N # 70341-N . Prevents accidental disconnects.
* France / Belgium Watertight extension cords available. View # 71015.
* Available in Color Dark Green. Part #71125-GRN
71130
FRANCE / BELGIUM LOCKING 16A-250V CEE 7/5 (FR1-16R) TYPE E IP66 / IP68 WATERTIGHT OUTLET (WITH GASKET), PANEL OR BOX MOUNT. BLUE.
Notes:
* # 71130 Watertight Socket Locks onto France / Belgium Plug # 71341. Prevents accidental disconnects.
* For surface mount applications use # 71325, 71320, 71322 wall boxes.
* France / Belgium Watertight extension cords available. View # 71015.
* Available in Color Dark Green. Part #71130-GRN
71125-GRN
FRANCE / BELGIUM LOCKING 16A-250V CEE 7/5 (FR1-16R) CEE 7/5 TYPE E IP66 / IP68 WATERTIGHT OUTLET (WITH GASKET), PANEL OR WALL BOX MOUNT. DARK GREEN.
Notes:
* # 71125-GRN Watertight Socket Locks onto France / Belgium Plug # 71341-GRN. Prevents accidental disconnects.
* France / Belgium Watertight extension cords available. View # 71015.
* Available in Color Blue. Part #71125
71130-GRN
FRANCE / BELGIUM LOCKING 16A-250V CEE 7/5 (FR1-16R) TYPE E IP66 / IP68 WATERTIGHT OUTLET (WITH GASKET), PANEL OR BOX MOUNT. DARK GREEN.
Notes:
* # 71130-GRN Watertight Socket Locks onto France / Belgium Plug # 71341-GRN. Prevents accidental disconnects.
* For surface mount applications use # 71325, 71320, 71322 wall boxes.
* France / Belgium Watertight extension cords available. View # 71015.
* Available in Color Blue. Part #71130
71110-WHT
FRANCE, BELGIUM CEE 7/5 TYPE E 16A-250V (FR1-16R) PANEL MOUNT OUTLET, SHUTTERED CONTACTS. WHITE.
Notes:
* Requires #97120-BZ wall plate when mounted on American 2x4 wall boxes.
* France, Belgium "locking" outlets #71125, #71130 available. Prevents accidental disconnects.
71120
FRANCE, BELGIUM 16A-250V WEATHERPROOF OUTLET (WITH GASKET), CEE 7/5 TYPE E (FR1-16R), (IP54 COVER CLOSED - IP20 COVER OPEN), PANEL OR WALL BOX MOUNT, "SHUTTERED CONTACTS". GRAY.
Notes:
* Mounts on American, European wall boxes or panel mount, DIN rail mount.
* Stainless steel wall plates #97120-BZ and #97120-DBZ mounts outlet onto American 2x4 and 4x4 wall boxes.
* France, Belgium "locking" outlets #71125, #71130 available. Prevents accidental disconnects.
74580-WP
AUSTRALIA / NEW ZEALAND 15A-250V PANEL MOUNT INLET (AU2-15P), WEATHERPROOF IP34. WHITE.
* For mobile equipment, RV, applications.
Notes:
* Panel mount inlet accepts Australia, New Zealand 20A, 15A, In-line connectors.
* For RV, camper, mobile home applications, Australia building wire available. # CNCP07AA002.
74120
AUSTRALIA / NEW ZEALAND 10A-250V PANEL MOUNT OUTLET TYPE I (AU1-10R), WEATHERPROOF IP44 RATED. WHITE.
Notes:
* For mobile equipment, RV applications.
* Australia TUV approved building wire/cable #CNCP07AA002.
* Outlet accepts 10 Ampere Australia / New Zealand plugs.
74180
AUSTRALIA / NEW ZEALAND 10A-250V PANEL MOUNT POWER INLET (AU1-10P). BLACK.
Notes:
* Panel mount inlet accepts Australia, New Zealand 20A, 15A, 10A In-line connectors.
74120-PFS
AUSTRALIA, NEW ZEALAND, CHINA 10A-250V WEATHERPROOF OUTLET TYPE I (AU1-10R), IP44 RATED, PANEL OR WALL BOX MOUNT. BLACK.
Notes:
* Stainless steel wall plates #97120-BZ and #97120-DBZ mounts outlet onto standard American 2x4 and 4x4 wall boxes.
* Not for use with #70125 wall box.
74520-A
AUSTRALIA / NEW ZEALAND 15A-250V / 10A-250V WEATHERPROOF PANEL OR WALL BOX MOUNT OUTLET TYPE I, AU2-15R, AU1-10R. BLACK.
Notes:
* Outlet accepts 15 Ampere & 10 Ampere Australia / New Zealand plugs.
* Stainless steel wall plates # 97120-BZ and # 97120-DBZ mounts outlet onto standard American 2x4 and 4x4 wall boxes.
* Not for use with # 70125 wall box.
72120-BLK
UNITED KINGDOM, UK, BRITISH 13A-250V IP54 WEATHERPROOF PANEL OR WALL BOX MOUNT OUTLET (UK1-13R), BS 1363A TYPE G SOCKET, SHUTTERED CONTACTS, 2 POLE-3 WIRE GROUNDING (2P+E). BLACK.
Notes:
* Stainless steel wall plates #97120-BZ and #97120-DBZ mounts outlet onto standard American 2X4 and 4X4 wall boxes.
* For surface mount applications use #70125 wall box.
* For DIN rail mount use #70125-DIN bracket with #70125 wall box.
75520-IT
ITALY, CHILE, EUROPEAN SCHUKO CEE 7/3 (EU1-16R) 16A-250V, 10A-250V CEI 23-50 (S11) CEI 23-16 TYPE L (IT1-10R) WEATHERPROOF PANEL OR WALL BOX MOUNT OUTLET. BLACK.
Notes:
* Accepts European Schuko type C, E, F, CEE 7, CEE 7/4, CEE 7/7 plugs, Europlug & Italy, Chile type L 10 Amp. plugs.
* Stainless steel wall plates #97120-BZ and #97120-DBZ mounts outlet onto standard American 2x4 and 4x4 wall boxes.
* Optional panel mount terminal shield #70127 available.
* Not for use with #70125 wall box.
75520
ITALY, CHILE 10/16A-250V CEI 23-50 (S17) (S11), CEI 23-16 TYPE L (IT1-10R/IT2-16R) IP44 WEATHERPROOF PANEL OR WALL BOX MOUNT OUTLET. BLUE.
Notes:
* Stainless steel wall plates #97120-BZ and #97120-DBZ mounts outlet onto standard American 2x4 and 4x4 wall boxes.
* For surface mount weatherproof applications use box #70125, weatherproof cover requires extra long stainless steel mounting screws. (extra long screws not included).
* For DIN rail mount use #70125-DIN bracket with #70125 wall box.
76120
SWISS 10A-250V WEATHERPROOF OUTLET IP54 (WITH GASKET) (SW1-10R) TYPE 13, PANEL OR WALL BOX MOUNT. GRAY.
Notes:
* Stainless steel wall plates #97120-BZ and #97120-DBZ mounts outlet onto standard American 2x4 and 4x4 wall boxes.
* For surface mount applications use #70125 wall box.
* For DIN rail mount use #70125-DIN bracket with #70125 wall box.
76120-NS
SWISS SN 441011, SEV 1011 10 AMPERE-250 VOLT WEATHERPROOF OUTLET WITH GASKET, IP55 RATED COVER CLOSED, IP20 COVER OPEN, PANEL OR WALL BOX MOUNT, TYPE T-13, 2 POLE-3 WIRE GROUNDING, BLACK WITH BLUE COVER.
Notes:
* Use plug 76140-SP with 76120-NS to maintain IP55 rating while in use.
* Stainless steel wall plates #97120-BZ, #97120-DBZ mounts outlet(s) onto standard American 2x4 and 4x4 wall boxes.
76520-NS
SWISS SN 441011, SEV 1011 16 AMPERE-250 VOLT WEATHERPROOF OUTLET WITH GASKET, IP55 RATED COVER CLOSED, IP20 COVER OPEN, PANEL OR WALL BOX MOUNT, TYPE T-23, 2 POLE-3 WIRE GROUNDING, BLACK WITH BLUE COVER.
Notes:
* Use 16 Amp plug 76540-SP with 76520-NS to maintain IP55 rating while in use.
* Stainless steel wall plates #97120-BZ, #97120-DBZ mounts outlet(s) onto standard American 2x4 and 4x4 wall boxes.
* 16 Amp outlet #76520-NS accepts 16A and 10A Swiss plugs.
78120
DENMARK, DANISH 16A-250V WEATHERPROOF (IP54 (DE1-13R) TYPE K OUTLET. GRAY.
Notes:
* Stainless steel wall plates #97120-BZ and #97120-DBZ mounts outlet onto standard American 2x4 and 4x4 wall boxes.
* For surface mount applications use #70125 wall box.
* For DIN rail mount use #70125-DIN bracket with #70125 wall box.
74900-WP
UNIVERSAL INTERNATIONAL, EUROPEAN, BRITISH, AUSTRALIA, ASIA, THAILAND MULTI-CONFIGURATION, 10A-250V WEATHERPROOF IP44 PANEL OR WALL BOX MOUNT POWER OUTLET, SHUTTERED CONTACTS, 2 POLE-3 WIRE GROUNDING (2P+E). BLACK.
Notes:
* Outlet accepts International European, British, Australia, American, South America, Asia, Thailand & Type D South Africa, India Plugs.
* Stainless steel wall plates # 97120-BZ and # 97120-DBZ mounts outlet onto standard American 2x4 and 4x4 wall boxes.
* Not for use with # 70125 wall box.
74720
CHINA 10A-250V WEATHERPROOF OUTLET WITH GASKET, (CH1-10R), PANEL OR WALL BOX MOUNT, IP44 RATED. BLACK.
Notes:
* Stainless steel wall plates #97120-BZ and #97120-DBZ mounts outlet onto standard American 2x4 and 4x4 wall boxes.
* Not for use with #70125 wall box.
85220
BRAZIL 10A-250V PANEL OR WALL BOX MOUNT OUTLET NBR 14136 TYPE N (BR2-10R), IP54 RATED. BLUE.
Notes:
* Stainless steel wall plates #97120-BZ and #97120-DBZ mounts outlet onto standard American 2x4 and 4x4 wall boxes.
* Not for use with #70125 wall box.
85220-BLK10
BRAZIL 10A-250V PANEL OR WALL BOX MOUNT OUTLET NBR 14136 TYPE N (BR2-10R), IP44 RATED. BLACK.
Notes:
* Stainless steel wall plates #97120-BZ and #97120-DBZ mounts outlet onto standard American 2x4 and 4x4 wall boxes.
* Not for use with #70125 wall box.
84270
ARGENTINA 10A-250V OUTLET (AR1-10R), IP54 RATED, PANEL OR WALL BOX MOUNT. BLUE.
Notes:
* Stainless steel wall plates #97120-BZ and #97120-DBZ mounts outlet onto standard American 2x4 and 4x4 wall boxes.
* For surface mount weatherproof applications use box #70125, weatherproof cover requires extra long stainless steel mounting screws. Extra long screws not included.
* For DIN rail mount use #70125-DIN bracket with #70125 wall box.
57011
IEC 60320 C-14 PANEL MOUNT INLET 15A-250V, 6.3 x 0.8 mm (0.250" x 0.032") Q.C. TERMINALS. BLACK.
57311
IEC 60320 C-14 15A-250V POWER INLET, SNAP-IN MOUNT, 6.3 x 0.8 mm (0.250" x 0.032") Q.C.TERMINALS. BLACK.
57710
IEC 60320 C-14 10A-250V PANEL MOUNT POWER INLET, SINGLE POLE (SPST) SWITCH, 4.8 x 0.8 mm (0.189” x 0.032”) TERMINALS. BLACK.
57720
IEC 60320 C-14 10A-250V SNAP-IN PANEL MOUNT POWER INLET, SINGLE POLE (SPST) SWITCH, 4.8 x 0.8 mm (0.189” x 0.032”) TERMINALS. BLACK.
57120
IEC 60320 C-13 POWER OUTLET, 15A/10A-250V, 6.3 x 0.8 mm (0.250" x 0.032") QUICK CONNECT TERMINALS. BLACK.
57320
IEC 60320, C-13 POWER OUTLET, 15/10A-250V, SNAP-IN MOUNT ON 1.5 mm THICK PANEL, 6.3 x 0.8 mm (0.250" x 0.032") TERMINALS. BLACK.
57320-LK
TRU-LOCK IEC 60320 LOCKING C-13 PANEL MOUNT OUTLET, UNIVERSAL APPROVALS, 15A-250V, 10A-250V, IMPACT RESISTANT NYLON (PA66), SNAP-IN MOUNT ON 1.5mm PANELS, 6.3 x 0.08mm (0.250 x 0.032"), QUICK CONNECT / SOLDER TERMINALS. BLACK.
Notes:
* Locking C13 receptacles designed to securely lock onto all C14 plugs, C14 power cords.
* IEC 60320 C-13 outlet locks onto IEC 60320 C-14 plugs. Red color button unlocks the C-14 plug.
* International approvals: C(RU)US, KEMA/KEUR, ENEC 05, CCC.
57350
IEC 60320 C-13/14 10A-250V SNAP-IN PANEL MOUNT POWER OUTLET/INLET, 4.8 x 0.8 mm (0.189" x 0.032") TERMINALS. BLACK.
57055-LK
TRU-LOCK IEC 60320, C-13 LOCKING CONNECTOR REWIREABLE, 15 AMP. 125V-250V, 10 AMP. 250 VOLT. BLACK.
Notes:
* Locking C13 connector designed to securely lock onto all C14 inlets, C14 plugs, C14 power cords.
* Max cable size = 9.0mm (0.354") dia.
* C-13 connector locks onto IEC 60320 C-14 inlets, PDU outlet strips, plugs, jumper cords. Red color release lever unlocks the C-13 connector.
* International approvals: C(UL)US, KEMA-KEUR, ENEC-05, PSE, AS/NZS 4417 RCM MARK, SGS
57055-NSL
IEC 60320 C-13 CONNECTOR, 15A-250V (UL/CSA), 10A-250V (VDE/CCC), ACCEPTS 14 AWG (2.5 mm2) CONDUCTORS, 10 mm (0.394") DIA. CORD, BLACK.
57055-NS
IEC 60320 C-13 CONNECTOR 15A-250V (UL/CSA), 10A-250V (VDE, CCC), ACCEPTS 18 AWG (1.0 mm2) CONDUCTORS, 8.5mm (0.335") DIA. CORDAGE, BLACK.
57030
IEC 60320 C-14 PLUG, 15A-250V, ACCEPTS 18 AWG (1.0 mm2) CONDUCTORS, 8.5 mm (0.335") DIA. CORDAGE. BLACK.
57030-NSL
IEC 60320 C-14 PLUG, 15A-250V (UL/CSA), 10A-250V (VDE, CCC), ACCEPTS 14 AWG (2.5 mm2) CONDUCTORS, 10 mm (0.394") DIA. CORDAGE, BLACK.
57080
IEC 60320 C-20 INLET, 20A-250V UL/CSA, 16A-250V VDE, SCREW TERMINALS. BLACK.
57081
IEC 60320 C-20 INLET, 20A-250V UL/CSA, 16A-250V VDE, 6.3 x 0.8 mm (0.250" x 0.032") Q.C. TABS. BLACK.
57745
IEC 60320 C-20 INLET, 20A-250V UL/CSA, 16A-250V VDE, SNAP-IN PANEL MOUNT, 6.3 x 0.8 mm (0.250" x 0.032") Q.D. TERMINALS. BLACK.
57730
IEC 60320 C-20 INLET, 20A-250V UL/CSA, 16A-250V VDE, ON/OFF SWITCH (DPST), PANEL MOUNT, 6.3 x 0.8 mm (0.250" x 0.032") Q.C. BLACK.
57735
IEC 60320 C-20 INLET, 20A-250V UL/CSA, 16A-250V VDE, ON/OFF SWITCH (DPST), SNAP-IN PANEL MOUNT, 6.3 x 0.8 mm (0.250" x 0.032") Q.D. BLACK.
57100-A
IEC 60320 C-19 OUTLET, 16A-250V, SCREW TERMINALS. BLACK.
57100
IEC 60320 C-19 OUTLET, 20A-250V UL/CSA, 16A-250V VDE, 6.3 x 0.8 mm (0.250 x 0.032") Q.C. TABS. BLACK.
57103
IEC 60320 C-19 OUTLET, SNAP-IN MOUNT, 21A-250V UL/CSA, 16A-250V VDE, 6.3 x 0.8 mm (0.250” x 0.032”) Q.D. TERMINALS. BLACK.
57103-LK
LOCKING IEC 60320 C-19 PANEL MOUNT POWER OUTLET, 16A-250V EUROPEAN APPROVED (ENEC 19, ASTA), 20A-250V C(RU)US (UL/CSA) APPROVED, SNAP-IN PANEL MOUNT. BLACK.
Notes:
* Locking C19 receptacles designed to securely lock onto all C20 plugs, C20 power cords.
57103-LKX1.0M
LOCKING IEC 60320 C-19 PANEL MOUNT POWER OUTLET, 16A-250V EUROPEAN APPROVED (ENEC 19, ASTA), 20A-250V C(RU)US (UL/CSA) APPROVED, SNAP-IN PANEL MOUNT. BLACK.
Notes:
* Locking C19 receptacles designed to securely lock onto all C20 plugs, C20 power cords.
57090-LK
TRU-LOCK IEC 60320, C-19 LOCKING CONNECTOR REWIREABLE, 20A-250V UL/CSA Rated, 16A-250V Europe/Australia rated, 2 POLE-3 WIRE GROUNDING (2P+E). BLACK.
Notes:
* Locking C19 connector designed to securely lock onto C20 power inlets, C20 plugs, C20 cords.
* Terminals accept 2.50mm conductors. Maximum cable diameter = 11.3mm (0.445").
* Terminal screw torque = 0.4Nm, Strain relief screw torque = 0.3Nm.
* Body Material Nylon, PA, PC LSZH (Low Smoke Zero Halogen).
57090
IEC 60320 C-19 CONNECTOR, 21A-250V UL/CSA, 16A-250V VDE, ACCEPTS 8-10 mm (0.315-0.394") DIA. CORD, BLACK.
57090-A
IEC 60320 C-19 CONNECTOR, 20A-250V UL/CSA, 16A-250V VDE, ACCEPTS 8.5-10 mm (0.335-0.394") DIA. CORD, BLACK.
57090-LK
TRU-LOCK IEC 60320, C-19 LOCKING CONNECTOR REWIREABLE, 20A-250V UL/CSA Rated, 16A-250V Europe/Australia rated, 2 POLE-3 WIRE GROUNDING (2P+E). BLACK.
Notes:
* Locking C19 connector designed to securely lock onto C20 power inlets, C20 plugs, C20 cords.
* Terminals accept 2.50mm conductors. Maximum cable diameter = 11.3mm (0.445").
* Terminal screw torque = 0.4Nm, Strain relief screw torque = 0.3Nm.
* Body Material Nylon, PA, PC LSZH (Low Smoke Zero Halogen).
57110
IEC 60320 C-20 PLUG, 20A-250V (UL,CSA), 16A-250V (VDE, CCC, ENEC 10). ACCEPTS 8-10 mm (0.315-0.394") DIA. CORD. BLACK.
57110-V
IEC 60320 C-20 PLUG, 20A-250V, ACCEPTS 12 AWG (4.0 mm2) CONDUCTORS, 12 mm (0.472") DIA. CORD, BLACK.
5278-SS
15A-125V NEMA 5-15P FLANGED PANEL MOUNT POWER INLET, IMPACT RESISTANT NYLON, SPECIFICATION GRADE. WHITE.
Notes:
* Weatherproof / dust proof applications use #5200-WC cover & #5200-WTC terminal shield or # 79480 WP Cover.
** NEMA Panel Mount Power Inlets with same mounting pattern listed below.
**NEMA 5-15P Inlet #5278-SS (15A-125V). Accepts NEMA 5-15R & NEMA 5-20R connectors.
**NEMA 5-20P Inlet #5378-SS (20A-125V). Accepts NEMA 5-20R connectors.
**NEMA 6-15P Inlet #5678-SS (15A-250V). Accepts NEMA 6-15R connectors & NEMA 6-20R connectors.
**NEMA 6-20P Inlet #5478-SS (20A-250V). Accepts NEMA 6-20R connectors.
**NEMA L5-15R LOCKING inlet #4716-SS (15A-125V). Accepts NEMA L5-15R Locking connectors.
**NEMA L6-15P LOCKING inlet #L615-FI (15A-250V). Accepts NEMA L6-15R Locking connectors.
View: High Power NEMA Locking 20A, 30A Power Inlets. NEMA Flanged Inlets & Outlets Guide
5279-SS
15A-125V NEMA 5-15R FLANGED PANEL MOUNT POWER OUTLET, SPECIFICATION GRADE. WHITE.
Notes:
* Weatherproof / dust proof applications use #5200-WSC cover & #5200-WTC terminal shield or # 79480 WP cover.
** NEMA Flanged Panel Mount Outlets with same mounting pattern listed below.
**NEMA 5-15R Outlet Part #5279-SS (15A-125V). Accepts NEMA 5-15P plugs.
**NEMA 5-20R Outlet Part #5379-SS (20A-125V). Accepts NEMA 5-20P & NEMA 5-15P plugs.
**NEMA 6-15R Outlet Part #5679-SS (15A-250V). Accepts NEMA 6-15P plugs.
**NEMA 6-20R Outlet Part #5479-SS (20A-250V). Accepts NEMA 6-20P & NEMA 6-15P plugs.
**NEMA L5-15R Locking Outlet #4715-SS (15A-125V). Accepts NEMA L5-15P Locking plugs.
**NEMA L6-15R Locking Outlet #L615-FO (15A-250V). Accepts NEMA L6-15P Locking plugs.
View: Optional panel mount designs # 5258-I, # 5258-QC (Quick Connect / Solder Terminals), # 70020 weather resistant.
70020-BLK-NS
15A-125V NEMA 5-15R WEATHERPROOF OUTLET, PANEL / WALL BOX MOUNT, TYPE B, IP54 RATED. BLACK.
Notes:
* American 2x4, 4x4 wall box mount applications = Use #97120-BZ, #97120-DBZ wall plates.
* Terminals, conductor cover for panel mount applications = Use #70127.
* Not for use with #70125 wall box.
View: Optional panel mount designs # 5279-SS, # 5258, # 5258-QC.
View: European, British, Australia, Universal Weatherproof outlets with same mounting design.
5378-SS
20A-125V NEMA 5-15P FLANGED PANEL MOUNT POWER INLET, IMPACT RESISTANT NYLON, SPECIFICATION GRADE. WHITE.
Notes:
* Weatherproof / dust proof applications use #5200-WC cover & #5200-WTC terminal shield or # 79480 WP Cover.
* Temp. range = -40°C to +75°C. Terminals accept 16AWG-10AWG. Max. torque = 11 in. lbs.
** NEMA Panel Mount Power Inlets with same mounting pattern listed below.
**NEMA 5-15P Inlet #5278-SS (15A-125V). Accepts NEMA 5-15R & NEMA 5-20R connectors.
**NEMA 5-20P Inlet #5378-SS (20A-125V). Accepts NEMA 5-20R connectors.
**NEMA 6-15P Inlet #5678-SS (15A-250V). Accepts NEMA 6-15R connectors & NEMA 6-20R connectors.
**NEMA 6-20P Inlet #5478-SS (20A-250V). Accepts NEMA 6-20R connectors.
**NEMA L5-15R LOCKING inlet #4716-SS (15A-125V). Accepts NEMA L5-15R Locking connectors.
**NEMA L6-15P LOCKING inlet #L615-FI (15A-250V). Accepts NEMA L6-15R Locking connectors.
View: High Power NEMA Locking 20A, 30A Power Inlets. NEMA Flanged Inlets & Outlets Guide
5379-SS
20A-125V NEMA 5-20R FLANGED PANEL MOUNT POWER OUTLET, SPECIFICATION GRADE. WHITE.
Notes:
* Weatherproof / dust proof applications use #5200-WSC cover & #5200-WTC terminal shield or # 79480 WP cover.
** NEMA Flanged Panel Mount Outlets with same mounting pattern listed below.
**NEMA 5-15R Outlet Part #5279-SS (15A-125V). Accepts NEMA 5-15P plugs.
**NEMA 5-20R Outlet Part #5379-SS (20A-125V). Accepts NEMA 5-20P & NEMA 5-15P plugs.
**NEMA 6-15R Outlet Part #5679-SS (15A-250V). Accepts NEMA 6-15P plugs.
**NEMA 6-20R Outlet Part #5479-SS (20A-250V). Accepts NEMA 6-20P & NEMA 6-15P plugs.
**NEMA L5-15R Locking Outlet #4715-SS (15A-125V). Accepts NEMA L5-15P Locking plugs.
**NEMA L6-15R Locking Outlet #L615-FO (15A-250V). Accepts NEMA L6-15P Locking plugs.
View: Optional panel mount designs # 5358-I, # 5358-QC (Quick Connect / Solder Terminals), # 70050-BLK weather resistant.
70050-BLK
20A-125V NEMA 5-20R WEATHERPROOF OUTLET, PANEL / WALL BOX MOUNT, TYPE B, IP44 RATED. BLACK.
Notes:
* American 2x4, 4x4 wall box mount applications = Use #97120-BZ, #97120-DBZ wall plates.
* Terminals, conductor cover for panel mount applications = Use #70127.
* Not for use with #70125 wall box.
View: Optional panel mount designs # 5379-SS, # 5358, # 5358-QC.
View: European, British, Australia, Universal Weatherproof outlets with same mounting design.
5678-SS
15A-250V NEMA 6-15P FLANGED PANEL MOUNT POWER INLET, IMPACT RESISTANT NYLON, SPECIFICATION GRADE. WHITE.
Notes:
* Weatherproof / dust proof applications use #5200-WC cover & #5200-WTC terminal shield or # 79480 WP Cover.
* Temp. range = -40°C to +75°C. Terminals accept 16AWG-10AWG. Max. torque = 11 in. lbs.
** NEMA Panel Mount Power Inlets with same mounting pattern listed below.
**NEMA 5-15P Inlet #5278-SS (15A-125V). Accepts NEMA 5-15R & NEMA 5-20R connectors.
**NEMA 5-20P Inlet #5378-SS (20A-125V). Accepts NEMA 5-20R connectors.
**NEMA 6-15P Inlet #5678-SS (15A-250V). Accepts NEMA 6-15R connectors & NEMA 6-20R connectors.
**NEMA 6-20P Inlet #5478-SS (20A-250V). Accepts NEMA 6-20R connectors.
**NEMA L5-15R LOCKING inlet #4716-SS (15A-125V). Accepts NEMA L5-15R Locking connectors.
**NEMA L6-15P LOCKING inlet #L615-FI (15A-250V). Accepts NEMA L6-15R Locking connectors.
View: High Power NEMA Locking 20A, 30A Power Inlets. NEMA Flanged Inlets & Outlets Guide
5679-SS
15A-250V NEMA 6-15R FLANGED PANEL MOUNT POWER OUTLET, IMPACT RESISTANT NYLON BODY, SPECIFICATION GRADE. WHITE.
Notes:
* Weatherproof / dust proof applications use #5200-WSC cover & #5200-WTC terminal shield or # 79480 WP cover.
** NEMA Flanged Panel Mount Outlets with same mounting pattern listed below.
**NEMA 5-15R Outlet Part #5279-SS (15A-125V). Accepts NEMA 5-15P plugs.
**NEMA 5-20R Outlet Part #5379-SS (20A-125V). Accepts NEMA 5-20P & NEMA 5-15P plugs.
**NEMA 6-15R Outlet Part #5679-SS (15A-250V). Accepts NEMA 6-15P plugs.
**NEMA 6-20R Outlet Part #5479-SS (20A-250V). Accepts NEMA 6-20P & NEMA 6-15P plugs.
**NEMA L5-15R Locking Outlet #4715-SS (15A-125V). Accepts NEMA L5-15P Locking plugs.
**NEMA L6-15R Locking Outlet #L615-FO (15A-250V). Accepts NEMA L6-15P Locking plugs.
View: Optional panel mount designs # 5658-I, # 5658-QC (Quick Connect / Solder Terminals).
5478-SS
20A-250V NEMA 6-20P FLANGED PANEL MOUNT POWER INLET, IMPACT RESISTANT NYLON, SPECIFICATION GRADE. WHITE.
Notes:
* Weatherproof / dust proof applications use #5200-WC cover & #5200-WTC terminal shield or # 79480 WP Cover.
* Temp. range = -40°C to +75°C. Terminals accept 16AWG-10AWG. Max. torque = 11 in. lbs.
** NEMA Panel Mount Power Inlets with same mounting pattern listed below.
**NEMA 5-15P Inlet #5278-SS (15A-125V). Accepts NEMA 5-15R & NEMA 5-20R connectors.
**NEMA 5-20P Inlet #5378-SS (20A-125V). Accepts NEMA 5-20R connectors.
**NEMA 6-15P Inlet #5678-SS (15A-250V). Accepts NEMA 6-15R connectors & NEMA 6-20R connectors.
**NEMA 6-20P Inlet #5478-SS (20A-250V). Accepts NEMA 6-20R connectors.
**NEMA L5-15R LOCKING inlet #4716-SS (15A-125V). Accepts NEMA L5-15R Locking connectors.
**NEMA L6-15P LOCKING inlet #L615-FI (15A-250V). Accepts NEMA L6-15R Locking connectors.
View: High Power NEMA Locking 20A, 30A Power Inlets. NEMA Flanged Inlets & Outlets Guide
* NEMA Plugs, Outlets, Power Cords, PDU Strips, Inlets, Outlets are listed below in related products. Scroll down to view.
5479-SS
20A-250V NEMA 6-20R FLANGED PANEL MOUNT POWER OUTLET, SPECIFICATION GRADE. WHITE.
Notes:
* Weatherproof / dust proof applications use #5200-WSC cover & #5200-WTC terminal shield or # 79480 WP cover.
** NEMA Flanged Panel Mount Outlets with same mounting pattern listed below.
**NEMA 5-15R Outlet Part #5279-SS (15A-125V). Accepts NEMA 5-15P plugs.
**NEMA 5-20R Outlet Part #5379-SS (20A-125V). Accepts NEMA 5-20P & NEMA 5-15P plugs.
**NEMA 6-15R Outlet Part #5679-SS (15A-250V). Accepts NEMA 6-15P plugs.
**NEMA 6-20R Outlet Part #5479-SS (20A-250V). Accepts NEMA 6-20P & NEMA 6-15P plugs.
**NEMA L5-15R Locking Outlet #4715-SS (15A-125V). Accepts NEMA L5-15P Locking plugs.
**NEMA L6-15R Locking Outlet #L615-FO (15A-250V). Accepts NEMA L6-15P Locking plugs.
View: Optional panel mount designs # 5858-QC (Quick Connect / Solder Terminals).
4716-SS
15A-125V NEMA L5-15P LOCKING FLANGED PANEL MOUNT POWER INLET, IMPACT RESISTANT NYLON, SPECIFICATION GRADE. WHITE.
Notes:
* Weatherproof / dust proof applications use #5200-WC cover & #5200-WTC terminal shield or # 79480 WP Cover.
* Temp. range = -40°C to +75°C. Terminals accept 16AWG-10AWG. Max. torque = 11 in. lbs.
** NEMA Panel Mount Power Inlets with same mounting pattern listed below.
**NEMA L5-15R LOCKING inlet #4716-SS (15A-125V). Accepts NEMA L5-15R Locking connectors.
**NEMA L6-15P LOCKING inlet #L615-FI (15A-250V). Accepts NEMA L6-15R Locking connectors.
**NEMA 5-15P Inlet #5278-SS (15A-125V). Accepts NEMA 5-15R & NEMA 5-20R connectors.
**NEMA 5-20P Inlet #5378-SS (20A-125V). Accepts NEMA 5-20R connectors.
**NEMA 6-15P Inlet #5678-SS (15A-250V). Accepts NEMA 6-15R connectors & NEMA 6-20R connectors.
**NEMA 6-20P Inlet #5478-SS (20A-250V). Accepts NEMA 6-20R connectors.
View: High Power NEMA Locking 20A, 30A Power Inlets. NEMA Flanged Inlets & Outlets Guide
4715-SS
15A-125V NEMA L5-15) FLANGED PANEL MOUNT POWER OUTLET, IMPACT RESISTANT NYLON BODY, SPECIFICATION GRADE. WHITE.
Notes:
* Weatherproof / dust proof applications use #5200-WSC cover & #5200-WTC terminal shield or # 79480 WP cover.
** NEMA Flanged Panel Mount Outlets with same mounting pattern listed below.
**NEMA L5-15R Locking Outlet #4715-SS (15A-125V). Accepts NEMA L5-15P Locking plugs.
**NEMA L6-15R Locking Outlet #L615-FO (15A-250V). Accepts NEMA L6-15P Locking plugs.
**NEMA 5-15R Outlet Part #5279-SS (15A-125V). Accepts NEMA 5-15P plugs.
**NEMA 5-20R Outlet Part #5379-SS (20A-125V). Accepts NEMA 5-20P & NEMA 5-15P plugs.
**NEMA 6-15R Outlet Part #5679-SS (15A-250V). Accepts NEMA 6-15P plugs.
**NEMA 6-20R Outlet Part #5479-SS (20A-250V). Accepts NEMA 6-20P & NEMA 6-15P plugs.
View: Optional panel mount design # 4710.
View: High Power NEMA Locking 20A, 30A Power Outlets. NEMA Flanged Outlets & Inlets Guide
L615-FI
15A-250V NEMA L6-15P LOCKING FLANGED PANEL MOUNT POWER INLET, IMPACT RESISTANT NYLON, SPECIFICATION GRADE. WHITE.
Notes:
* Weatherproof / dust proof applications use #5200-WC cover & #5200-WTC terminal shield or # 79480 WP Cover.
* Temp. range = -40°C to +75°C. Terminals accept 16AWG-10AWG. Max. torque = 11 in. lbs.
** NEMA Panel Mount Power Inlets with same mounting pattern listed below.
**NEMA 5-15P Inlet #5278-SS (15A-125V). Accepts NEMA 5-15R & NEMA 5-20R connectors.
**NEMA 5-20P Inlet #5378-SS (20A-125V). Accepts NEMA 5-20R connectors.
**NEMA 6-15P Inlet #5678-SS (15A-250V). Accepts NEMA 6-15R connectors & NEMA 6-20R connectors.
**NEMA 6-20P Inlet #5478-SS (20A-250V). Accepts NEMA 6-20R connectors.
**NEMA L5-15R LOCKING inlet #4716-SS (15A-125V). Accepts NEMA L5-15R Locking connectors.
**NEMA L6-15P LOCKING inlet #L615-FI (15A-250V). Accepts NEMA L6-15R Locking connectors.
View: High Power NEMA Locking 20A, 30A Power Inlets. NEMA Flanged Inlets & Outlets Guide
L615-FO
15A-250V NEMA L6-15R FLANGED PANEL MOUNT POWER OUTLET, IMPACT RESISTANT NYLON BODY, SPECIFICATION GRADE. WHITE.
Notes:
* Weatherproof / dust proof applications use #5200-WSC cover & #5200-WTC terminal shield or # 79480 WP cover.
* Temp. range = -40°C to +75°C. Terminals accept 16AWG-10AWG. Max. torque = 11 in. lbs.
** NEMA Flanged Panel Mount Outlets with same mounting pattern listed below.
**NEMA L5-15R Locking Outlet #4715-SS (15A-125V). Accepts NEMA L5-15P Locking plugs.
**NEMA L6-15R Locking Outlet #L615-FO (15A-250V). Accepts NEMA L6-15P Locking plugs.
**NEMA 5-15R Outlet Part #5279-SS (15A-125V). Accepts NEMA 5-15P plugs.
**NEMA 5-20R Outlet Part #5379-SS (20A-125V). Accepts NEMA 5-20P & NEMA 5-15P plugs.
**NEMA 6-15R Outlet Part #5679-SS (15A-250V). Accepts NEMA 6-15P plugs.
**NEMA 6-20R Outlet Part #5479-SS (20A-250V). Accepts NEMA 6-20P & NEMA 6-15P plugs.
View: Optional panel mount design # 4560.
View: High Power NEMA Locking 20A, 30A Power Outlets. NEMA Flanged Outlets & Inlets Guide
* Plugs, power cords, outlets, PDU strips, connectors, inlets, adapters are listed below in related products. Scroll down to view.
L520-FI
20A-125V NEMA L5-20P LOCKING FLANGED PANEL MOUNT POWER INLET, IMPACT RESISTANT NYLON BODY, SPECIFICATION GRADE. WHITE.
Notes:
* For weatherproof / dust proof applications use #5201-WC cover or #79485 cover.
* NEMA Panel Mount Power Inlets with same mounting design listed below.
**NEMA #L5-20FI Locking Inlet(20A-125V). Accepts Nema L5-20C Connectors.
**NEMA #L5-30FI Locking Inlet(30A-125V). Accepts Nema L5-30C Connectors.
**NEMA #L6-20FI Locking Inlet(20A-250V). Accepts Nema L6-20C Connectors.
**NEMA #L6-30FI Locking Inlet(30A-250V). Accepts Nema L6-30C Connectors.
View: High Power NEMA Locking 20A, 30A Power Inlets. NEMA Flanged Outlets & Inlets Guide
L520-FO
20A-125V NEMA L5-20R FLANGED PANEL MOUNT POWER OUTLET, IMPACT RESISTANT NYLON BODY, SPECIFICATION GRADE. WHITE.
Notes:
* For weatherproof / dust proof applications use #5203-WSC cover or #79485 cover.
** NEMA Flanged Panel Mount Outlets with same mounting pattern listed below.
**NEMA L5-20R Locking Outlet #L520-FO (20A-125V). Accepts NEMA L5-20P Locking plugs.
**NEMA L5-30R Locking Outlet #L530-FO (30A-125V). Accepts NEMA L5-30P Locking plugs.
**NEMA L6-20R Locking Outlet #L620-FO (20A-250V). Accepts NEMA L6-20P Locking plugs.
**NEMA L6-30R Locking Outlet #L630-FO (30A-250V). Accepts NEMA L6-30P Locking plugs.
View: Optional panel mount design # L520-R.
View: High Power NEMA Locking 20A, 30A Power Outlets. NEMA Flanged Outlets & Inlets Guide
L620-FI
20A-250V NEMA L6-20P LOCKING FLANGED PANEL MOUNT POWER INLET, IMPACT RESISTANT NYLON BODY, SPECIFICATION GRADE. WHITE.
Notes:
* For weatherproof / dust proof applications use #5201-WC cover or #79485 cover.
* NEMA Panel Mount Power Inlets with same mounting design listed below.
**NEMA #L5-20FI Locking Inlet(20A-125V). Accepts Nema L5-20C Connectors.
**NEMA #L5-30FI Locking Inlet(30A-125V). Accepts Nema L5-30C Connectors.
**NEMA #L6-20FI Locking Inlet(20A-250V). Accepts Nema L6-20C Connectors.
**NEMA #L6-30FI Locking Inlet(30A-250V). Accepts Nema L6-30C Connectors.
View: High Power NEMA Locking 20A, 30A Power Inlets. NEMA Flanged Outlets & Inlets Guide
L620-FO
20A-250V NEMA L6-20R FLANGED PANEL MOUNT POWER OUTLET, IMPACT RESISTANT NYLON BODY, SPECIFICATION GRADE. WHITE.
Notes:
* For weatherproof / dust proof applications use #5203-WSC cover or #79485 cover.
** NEMA Flanged Panel Mount Outlets with same mounting pattern listed below.
**NEMA L5-20R Locking Outlet #L520-FO (20A-125V). Accepts NEMA L5-20P Locking plugs.
**NEMA L5-30R Locking Outlet #L530-FO (30A-125V). Accepts NEMA L5-30P Locking plugs.
**NEMA L6-20R Locking Outlet #L620-FO (20A-250V). Accepts NEMA L6-20P Locking plugs.
**NEMA L6-30R Locking Outlet #L630-FO (30A-250V). Accepts NEMA L6-30P Locking plugs.
View: Optional panel mount design # L620-R.
View: High Power NEMA Locking 20A, 30A Power Outlets. NEMA Flanged Outlets & Inlets Guide
L530-FI
30A-125V NEMA L5-30P LOCKING FLANGED PANEL MOUNT POWER INLET, IMPACT RESISTANT NYLON BODY, SPECIFICATION GRADE. WHITE.
Notes:
* For weatherproof / dust proof applications use #5201-WC cover or #79485 cover.
* NEMA Panel Mount Power Inlets with same mounting design listed below.
**NEMA #L5-20FI Locking Inlet(20A-125V). Accepts Nema L5-20C Connectors.
**NEMA #L5-30FI Locking Inlet(30A-125V). Accepts Nema L5-30C Connectors.
**NEMA #L6-20FI Locking Inlet(20A-250V). Accepts Nema L6-20C Connectors.
**NEMA #L6-30FI Locking Inlet(30A-250V). Accepts Nema L6-30C Connectors.
View: High Power NEMA Locking 20A, 30A Power inlets. NEMA Flanged Outlets & Inlets Guide
L530-FO
30A-125V NEMA L5-30R FLANGED PANEL MOUNT POWER OUTLET, IMPACT RESISTANT NYLON BODY, SPECIFICATION GRADE. WHITE.
Notes:
* For weatherproof / dust proof applications use #5203-WSC cover or #79485 cover.
** NEMA Flanged Panel Mount Outlets with same mounting pattern listed below.
**NEMA L5-20R Locking Outlet #L520-FO (20A-125V). Accepts NEMA L5-20P Locking plugs.
**NEMA L5-30R Locking Outlet #L530-FO (30A-125V). Accepts NEMA L5-30P Locking plugs.
**NEMA L6-20R Locking Outlet #L620-FO (20A-250V). Accepts NEMA L6-20P Locking plugs.
**NEMA L6-30R Locking Outlet #L630-FO (30A-250V). Accepts NEMA L6-30P Locking plugs.
View: Optional panel mount design # L530-R.
View: High Power NEMA Locking 20A, 30A Power Outlets. NEMA Flanged Outlets & Inlets Guide
L630-FI
30A-250V NEMA L6-30P LOCKING FLANGED PANEL MOUNT POWER INLET, IMPACT RESISTANT NYLON BODY, SPECIFICATION GRADE. WHITE.
Notes:
* For weatherproof / dust proof applications use #5201-WC cover or #79485 cover.
* NEMA Panel Mount Power Inlets with same mounting design listed below.
**NEMA #L5-20FI Locking Inlet(20A-125V). Accepts Nema L5-20C Connectors.
**NEMA #L5-30FI Locking Inlet(30A-125V). Accepts Nema L5-30C Connectors.
**NEMA #L6-20FI Locking Inlet(20A-250V). Accepts Nema L6-20C Connectors.
**NEMA #L6-30FI Locking Inlet(30A-250V). Accepts Nema L6-30C Connectors.
View: High Power NEMA Locking 20A, 30A Power Inlets. NEMA Flanged Outlets & Inlets Guide
L630-FO
30A-250V NEMA L6-30R FLANGED PANEL MOUNT POWER OUTLET, IMPACT RESISTANT NYLON BODY, SPECIFICATION GRADE. WHITE.
Notes:
* For weatherproof / dust proof applications use #5203-WSC cover or #79485 cover.
** NEMA Flanged Panel Mount Outlets with same mounting pattern listed below.
**NEMA L5-20R Locking Outlet #L520-FO (20A-125V). Accepts NEMA L5-20P Locking plugs.
**NEMA L5-30R Locking Outlet #L530-FO (30A-125V). Accepts NEMA L5-30P Locking plugs.
**NEMA L6-20R Locking Outlet #L620-FO (20A-250V). Accepts NEMA L6-20P Locking plugs.
**NEMA L6-30R Locking Outlet #L630-FO (30A-250V). Accepts NEMA L6-30P Locking plugs.
View: Optional panel mount design # L630-R.
View: High Power NEMA Locking 20A, 30A Power Outlets. NEMA Flanged Outlets & Inlets Guide
L1420-FI
20A-125/250V NEMA L14-20P FLANGED PANEL MOUNT POWER INLET, SPECIFICATION GRADE. WHITE.
Notes:
* Weatherproof / dust proof applications use #5202-WC cover or #79485 cover.
View: Mating power connector # L1420-C.
View: High Power NEMA Locking 20A- 30A (4Pole / 5 Pole) Inlets & Outlets. NEMA Flanged Outlets & Inlets Guide
L1420-FO
20A-125/250V NEMA L14-20R FLANGED PANEL MOUNT POWER OUTLET, SPECIFICATION GRADE. WHITE.
Notes:
* Weatherproof / dust proof applications use #5205-WSC cover or #79485 cover.
View: Optional panel mount design # L1420-R.
View: High Power NEMA Locking 20A- 30A (4 Pole / 5 Pole) Outlets & Inlets. NEMA Flanged Outlets & Inlets Guide
L1430-FI
30A-125/250V NEMA L14-30P FLANGED PANEL MOUNT POWER INLET, IMPACT RESISTANT NYLON BODY, SPECIFICATION GRADE. WHITE.
Notes:
* Weatherproof / dust proof applications use #5202-WC cover or #79485 cover.
View: Mating power connector # L1430-C.
View: High Power NEMA Locking 20A- 30A (4Pole / 5 Pole) Inlets & Outlets. NEMA Flanged Outlets & Inlets Guide
L1430-FO
30A-250V NEMA L14-30R FLANGED PANEL MOUNT POWER OUTLET, IMPACT RESISTANT NYLON BODY, SPECIFICATION GRADE. WHITE.
Notes:
* Weatherproof / dust proof applications use #5205-WSC cover or #79485 cover.
View: Optional panel mount design # L1430-R.
View: High Power NEMA Locking 20A- 30A (4 Pole / 5 Pole) Outlets & Inlets. NEMA Flanged Outlets & Inlets Guide
L1520-FI
20 AMPERE-250 VOLT, 3 PHASE (X,Y,Z,+G) NEMA L15-20P LOCKING FLANGED PANEL MOUNT POWER INLET. WHITE.
Notes:
* Weatherproof / dust proof applications use #5202-WC cover or #79485 cover.
View: Mating power connector # L1520-C.
View: High Power NEMA Locking 20A- 30A (4Pole / 5 Pole) Inlets & Outlets. NEMA Flanged Outlets & Inlets Guide
L1520-FO
20 AMPERE-250 VOLT, 3 PHASE (X,Y,Z,+G) NEMA L15-20R LOCKING FLANGED PANEL MOUNT POWER OUTLET. WHITE.
Notes:
* Weatherproof / dust proof applications use #5205-WSC cover or #79485 cover.
View: Optional panel mount design # L1520-R.
View: High Power NEMA Locking 20A- 30A (4 Pole / 5 Pole) Outlets & Inlets. NEMA Flanged Outlets & Inlets Guide
L1530-FI
30 AMPERE-250 VOLT, 3 PHASE (X,Y,Z,+G) NEMA L15-30P LOCKING FLANGED PANEL MOUNT POWER INLET. WHITE.
Notes:
* Weatherproof / dust proof applications use #5202-WC cover or #79485 cover.
View: Mating power connector # L1530-C.
View: High Power NEMA Locking 20A- 30A (4Pole / 5 Pole) Inlets & Outlets. NEMA Flanged Outlets & Inlets Guide
L1530-FO
30 AMPERE-250 VOLT, 3 PHASE (X,Y,Z,+G) NEMA L15-30R LOCKING FLANGED PANEL MOUNT POWER OUTLET. WHITE.
Notes:
* Weatherproof / dust proof applications use #5205-WSC cover or #79485 cover.
View: Optional panel mount design # L1530-R.
View: High Power NEMA Locking 20A- 30A (4 Pole / 5 Pole) Outlets & Inlets. NEMA Flanged Outlets & Inlets Guide
L1620-FI
20 AMPERE-480 VOLT, 3 PHASE (X,Y,Z,+G) NEMA L16-20P LOCKING FLANGED PANEL MOUNT POWER INLET. WHITE.
Notes:
* Weatherproof / dust proof applications use #5202-WC cover or #79485 cover.
View: Mating power connector # L1620-C.
View: High Power NEMA Locking 20A- 30A (4Pole / 5 Pole) Inlets & Outlets. NEMA Flanged Outlets & Inlets Guide
L1620-FO
20 AMPERE-480, 3 PHASE (X,Y,Z,+G) NEMA L16-20R LOCKING FLANGED PANEL MOUNT POWER OUTLET. WHITE.
Notes:
* Weatherproof / dust proof applications use #5205-WSC cover or #79485 cover. < .
View: Optional panel mount design # L1620-R.
View: High Power NEMA Locking 20A- 30A (4 Pole / 5 Pole) Outlets & Inlets. NEMA Flanged Outlets & Inlets Guide
L1630-FI
30 AMPERE-480 VOLT, 3 PHASE (X,Y,Z,+G) NEMA L16-30P LOCKING FLANGED PANEL MOUNT POWER INLET. WHITE.
Notes:
* Weatherproof / dust proof applications use #5202-WC cover or #79485 cover.
View: Mating power connector # L1630-C.
View: High Power NEMA Locking 20A- 30A (4Pole / 5 Pole) Inlets & Outlets. NEMA Flanged Outlets & Inlets Guide
L1630-FO
30 AMPERE-480, 3 PHASE (X,Y,Z,+G) NEMA L16-30R LOCKING FLANGED PANEL MOUNT POWER OUTLET, 3 POLE-4 WIRE GROUNDING (3P+E), IMPACT RESISTANT NYLON BODY, SPECIFICATION GRADE. WHITE.
Notes:
* Weatherproof / dust proof applications use #5205-WSC cover or #79485 cover.
View: Optional panel mount design # L1630-R.
View: High Power NEMA Locking 20A- 30A (4 Pole / 5 Pole) Outlets & Inlets. NEMA Flanged Outlets & Inlets Guide
L2120-FI
20A-120/208V AC, 3 PHASE Y, NEMA L21-20P LOCKING FLANGED INLET, IMPACT RESISTANT NYLON BODY. WHITE.
Notes:
* For weatherproof / dustproof panel mount applications use #5202-WC inlet cover.
L2120-FO
20A-120/208V AC, 3 PHASE Y, NEMA L21-20FO LOCKING FLANGED OUTLET, IMPACT RESISTANT NYLON BODY. WHITE.
L2130-FI
30A-120/208V AC, 3 PHASE Y, NEMA L21-30P LOCKING FLANGED INLET, IMPACT RESISTANT NYLON BODY. WHITE.
Notes:
* For weatherproof / dustproof panel mount applications use #5202-WC inlet cover.
L2130-FO
30A-120/208V AC, 3 PHASE Y, NEMA L21-30FO LOCKING FLANGED OUTLET, IMPACT RESISTANT NYLON BODY. WHITE.
L2220-FI
20A-277/480V AC, 3 PHASE Y, NEMA L22-20P LOCKING FLANGED INLET, IMPACT RESISTANT NYLON BODY. WHITE.
Notes:
* For weatherproof / dustproof panel mount applications use #5202-WC inlet cover.
L2220-FO
20A-277/480V AC, 3 PHASE Y, NEMA L22-20FO LOCKING FLANGED OUTLET, IMPACT RESISTANT NYLON BODY. WHITE.
L2230-FI
30A-277/480V AC, 3 PHASE Y, NEMA L22-30P LOCKING FLANGED INLET, IMPACT RESISTANT NYLON BODY. WHITE.
Notes:
* For weatherproof / dustproof panel mount applications use #5202-WC inlet cover.
L2230-FO
30A-277/480V AC, 3 PHASE Y, NEMA L22-30FO LOCKING FLANGED OUTLET, IMPACT RESISTANT NYLON BODY. WHITE.
999-6134-NS
IEC 60309 (4h) PIN & SLEEVE PANEL MOUNT FLANGED INLET, 16A 110-130V (2P+E), SPLASHPROOF (IP44). 56mmX56mm C TO C MOUNTING. YELLOW. EUROPEAN OVE APPROVAL.
PIN AND SLEEVE IEC 60309 BROCHURE.
999-1216-NS
IEC 60309 (4h) PIN & SLEEVE PANEL MOUNT ANGLED RECEPTACLE OUTLET, 16A 110-130V (2P+E), SPLASHPROOF (IP44), 60mmX73mm C TO C MOUNTING. YELLOW. EUROPEAN OVE APPROVAL. PIN AND SLEEVE IEC 60309 BROCHURE.
888-6134-NS
IEC 60309 (4h) PIN & SLEEVE PANEL MOUNT FLANGED INLET, 20A-120V (2P+E), SPLASHPROOF (IP44). 56mmX56mm C TO C MOUNTING. YELLOW. C(UL)US APPROVED. PIN AND SLEEVE IEC 60309 BROCHURE.
888-1216-NS
IEC 60309 (4h) PIN & SLEEVE PANEL MOUNT ANGLED RECEPTACLE OUTLET, 20A-120V (2P+E), SPLASHPROOF (IP44), 60mmX73mm C TO C MOUNTING. YELLOW. C(UL)US APPROVED. PIN AND SLEEVE IEC 60309 BROCHURE.
888-6234-NS
IEC 60309 (4h) PIN & SLEEVE PANEL MOUNT FLANGED INLET, 30A-120V (2P+E), SPLASHPROOF (IP44). 56mmX56mm C TO C MOUNTING. YELLOW. C(UL)US APPROVED. PIN AND SLEEVE IEC 60309 BROCHURE.
888-1228-NS
IEC 60309 (4h) PIN & SLEEVE PANEL MOUNT ANGLED RECEPTACLE OUTLET, 30A-120V (2P+E), SPLASHPROOF (IP44). 60mmX73mm C TO C MOUNTING. YELLOW. C(UL)US APPROVED. PIN AND SLEEVE IEC 60309 BROCHURE.
888-6136-NS
IEC 60309 (6h) PIN & SLEEVE STRAIGHT POWER INLET, 20A/16A-220/250V (2P+E), SPLASHPROOF (IP44), CEE 17, IEC 309. C(UL)US LISTED & EUROPEAN OVE (UNIVERSAL APPROVALS). 56mmX56mm C TO C MOUNTING. BLUE. PIN AND SLEEVE IEC 60309 BROCHURE.
999-1154210
IEC 60309 (6h), 16A-250V, FLUSH MOUNT POWER INLET, SPLASHPROOF (IP44), 2 POLE-3 WIRE GROUNDING (2P+E). BEIGE. EUROPEAN APPROVALS.
Notes:
* Applications = European / International exported equipment, mobile units, RV, caravans, trailers, vans.
* Mating in-line connector #888-3126-NS.
888-1217-NS
IEC 60309 (6h) PIN & SLEEVE ANGLED RECEPTACLE OUTLET, 20A/16A-220/250V (2P+E), SPLASHPROOF (IP44), CEE 17, IEC 309. C(UL)US LISTED & EUROPEAN OVE (UNIVERSAL APPROVALS). 60mmX73mm C TO C MOUNTING. BLUE. PIN AND SLEEVE IEC 60309 BROCHURE.
888-6236-NS
IEC 60309 (6h) 30A-250V C(UL)US, 32A-220V OVE, SPLASHPROOF (IP44) PANEL MOUNT POWER INLET, UNIVERSAL APPROVALS, 56mmX56mm C TO C MOUNTING,BLUE. PIN AND SLEEVE IEC 60309 BROCHURE.
888-1229-NS
IEC 60309 (6h) 30A/32A-220/250V (2P+E) SPLASHPROOF (IP44) ANGLED PANEL MOUNT OUTLET, UNIVERSAL APPROVALS, 73.5mmX60mm C TO C MOUNTING. BLUE. PIN AND SLEEVE IEC 60309 BROCHURE.
888-7156-NS
IEC 60309 (6h) PIN & SLEEVE 3 PHASE PANEL MOUNT INLET, 20A-200/415V C(UL)US, 16A-220/380V - 240/415V OVE, (3P+N+E) SPLASHPROOF (IP44) UNIVERSAL, 56mmX56mm C TO C MOUNTING. RED. PIN AND SLEEVE IEC 60309 BROCHURE.
888-1227-NS
IEC 60309 (6h) PIN & SLEEVE 3 PHASE ANGLED PANEL MOUNT RECEPTACLE OUTLET, 20A-200/415V C(UL)US, 16A-220/380V - 240/415V OVE, (3P+N+E) SPLASHPROOF (IP44) UNIVERSAL ANGLED PANEL MOUNT OUTLET, 73.5mmX60mm C TO C MOUNTING. RED. PIN AND SLEEVE IEC 60309 BROCHURE.
888-6256-NS
IEC 60309 (6h) 3 PHASE INLET, 30A-200/415V C(UL)US, 32A-220/380V, 240/415V OVE, (3P+N+E) SPLASHPROOF (IP44) UNIVERSAL PANEL MOUNT INLET, 56mmX56mm C TO C MOUNTING. RED. PIN AND SLEEVE IEC 60309 BROCHURE.
888-1239-NS
IEC 60309 (6h) 3 PHASE OUTLET, 30A-200/415V C(UL)US, 32A-220/380V - 240/415V OVE, (3P+N+E) SPLASHPROOF (IP44) UNIVERSAL ANGLED PANEL MOUNT OUTLET. RED. NOTE: 73.5mmX60mm C TO C MOUNTING. PIN AND SLEEVE IEC 60309 BROCHURE.
888-661306
IEC 60309 (6h) 60A/63A-250V (2P+E) SPLASHPROOF (IP44) DOWN ANGLE POWER INLET, UNIVERSAL APPROVALS, 90mmX90mm C TO C MOUNTING. BLUE. PIN AND SLEEVE IEC 60309 BROCHURE.
888-560306
IEC 60309 (6h) 60A/63A-250V (2P+E) SPLASHPROOF (IP44) ANGLED PANEL/SURFACE MOUNT OUTLET, UNIVERSAL APPROVALS, 77mmX85mm C TO C MOUNTING. BLUE. PIN AND SLEEVE IEC 60309 BROCHURE.
888-665
IEC 60309 (6h) 3 PHASE INLET, 60A-380/415V (400 VOLT), 63A-220/380V - 240/415V (400 V0LT) EUROPEAN (3P+N+E), WATERTIGHT (IP67) & SPLASHPROOF (IP44) FLANGED POWER INLET, UNIVERSAL APPROVALS, 90mmX90mm C TO C MOUNTING. RED. PIN AND SLEEVE IEC 60309 BROCHURE.
888-129
IEC 60309 (6h) 3 PHASE OUTLET, 60A-380/415V (400 VOLT) UL/CSA, 63A-220/380V - 240/415V (400 V0LT) EUROPEAN (3P+N+E), WATERTIGHT (IP67) ANGLED FLANGED OUTLET, UNIVERSAL APPROVALS, 77mmX85mm C TO C MOUNTING. RED. PIN AND SLEEVE IEC 60309 BROCHURE.
888-679
IEC 60309 (6h) 3 PHASE INLET, 100A-380/415V (400 VOLT) UL/CSA, 125A-220/380V-240/415V (400 V0LT) EUROPEAN (3P+N+E), WATERTIGHT (IP67) POWER INLET, UNIVERSAL APPROVALS, 104mmX104mm C TO C MOUNTING. RED. PIN AND SLEEVE IEC 60309 BROCHURE.
888-12108
IEC 60309 (6h) 3 PHASE OUTLET, 100A-380/415V (400 VOLT) UL/CSA, 125A-220/380V - 240/415V (400 V0LT) EUROPEAN (3P+N+E), WATERTIGHT (IP67) ANGLED OUTLET, UNIVERSAL APPROVALS, 90mmX90mm C TO C MOUNTING. RED. PIN AND SLEEVE IEC 60309 BROCHURE.
70310-NS
EUROPEAN SCHUKO LOCKING 16A-250V CEE 7/3 (EU1-16R) TYPE F, IP66 / IP68 WATERTIGHT OUTLET (WITH GASKET), PANEL OR BOX MOUNT. BLUE.
Notes:
* # 70310-NS Outlet locks onto Watertight Plug # 70341-N . Prevents accidental disconnects.
* # 70310-NS Outlet locks onto Watertight Plug # 71441. Prevents accidental disconnects.
* European Schuko Watertight Extension cords available. View # 70025.
* Surface mount applications = Use # 71325,71320,71322 wall boxes listed below in related products.
* Available in Color Dark Green. Part #70310-NS-GRN
70300
EUROPEAN SCHUKO LOCKING 16A-250V CEE 7/3 (EU1-16R) TYPE F, IP66 / IP68 WATERTIGHT OUTLET, PANEL OR WALL BOX MOUNT (WITH GASKET), 2 POLE-3 WIRE GROUNDING (2P+E). BLUE.
Notes:
* # 70300 Outlet locks onto Watertight Plug # 70341-N . Prevents accidental disconnects.
* # 70300 Outlet locks onto Watertight Plug # 71441. Prevents accidental disconnects.
* # 70025 Watertight Extension cords available. View # 70025.
* Available in Color Dark Green. Part #70300-GRN
70190
EUROPEAN CEE 7/7 (EU1-16P) SCHUKO TYPE E, F, 16A-250V WEATHERPROOF IP44 POWER INLET. BLACK.
Notes:
* # 70190 Accepts European Schuko # 70161 (EU1-16R), France / Belgium # 71161 (FR1-16R) type connectors.
* IP68 Rated Watertight option listed below.
* # 71442 , 71443 , 71444 Watertight Power Inlets Lock onto Schuko Connector # 71445 . Prevents accidental disconnects.
70395
EUROPEAN SCHUKO 16 AMPERE 220-250 VOLT, 50/60 Hz, IP68 WATERTIGHT LOCKING FLANGE MOUNT (60mm-60mm) POWER INLET WITH GASKET AND CLOSURE COVER, CEE 7/4 TYPE E (EU1-16P), PANEL MOUNT OR WALL BOX MOUNT, 2 POLE-3 WIRE GROUNDING (2P+E). NYLON. GRAY / BLUE.
Notes:
* 70395 Watertight Power Inlet Locks onto Schuko Connector # 70361 . Prevents accidental disconnects.
* Material = Thermoplastic Elastomer, Temperature Range: -15°C to +70°C.
* European Schuko Watertight Extension cords available. View # 70025.
70120-LFL-WHT
EUROPEAN SCHUKO 16A-250V CEE 7/3 TYPE F OUTLET (EU1-16R), 50mmX50mm SIZE, PANEL OR WALL BOX MOUNT. WHITE.
Notes:
* Stainless steel wall plates #97120-BZ and #97120-DBZ mounts outlet onto standard American 2x4 and 4x4 wall boxes.
* Optional panel mount terminal shield #70127 available.
* European Schuko "locking" outlet #70300 available. Prevents accidental disconnects.
70120
EUROPEAN SCHUKO CEE 7/3 TYPE F (EU1-16R) 16A-250V WEATHERPROOF IP54 POWER OUTLET, PANEL OR WALL BOX MOUNT. GRAY FLIP LID, GRAY BASE.
Notes:
* Stainless steel wall plates #97120-BZ and #97120-DBZ mounts outlet onto standard American 2x4 and 4x4 wall boxes.
* For surface mount use #70125 wall box.
* For DIN rail mount use #70125-DIN bracket with #70125 wall box.
* Optional panel mount terminal shield #70127 available.
* European Schuko "locking" outlet #70300 available. Prevents accidental disconnects.
70120-BLK
EUROPEAN SCHUKO CEE 7/3 TYPE F (EU1-16R) 16A-250V WEATHERPROOF IP54 POWER OUTLET, PANEL OR WALL BOX MOUNT. BLACK.
Notes:
* Stainless steel wall plates #97120-BZ and #97120-DBZ mounts outlet onto standard American 2x4 and 4x4 wall boxes.
* For surface mount use #70125 wall box.
* For DIN rail mount use #70125-DIN bracket with #70125 wall box.
* Optional panel mount terminal shield #70127 available.
* European Schuko "locking" outlet #70300 available. Prevents accidental disconnects.
70120-BLK-GC
EUROPEAN SCHUKO CEE 7/3 TYPE F (EU1-16R) 16A-250V WEATHERPROOF IP54 POWER OUTLET, PANEL OR WALL BOX MOUNT. BLACK BASE, GRAY FLIP LID COVER.
Notes:
* Stainless steel wall plates #97120-BZ and #97120-DBZ mounts outlet onto standard American 2x4 and 4x4 wall boxes.
* For surface mount use #70125 wall box.
* For DIN rail mount use #70125-DIN bracket with #70125 wall box.
* Optional panel mount terminal shield #70127 available.
* European Schuko "locking" outlet #70300 available. Prevents accidental disconnects.
71125
FRANCE / BELGIUM LOCKING 16A-250V CEE 7/5 (FR1-16R) CEE 7/5 TYPE E IP66 / IP68 WATERTIGHT OUTLET (WITH GASKET), PANEL OR WALL BOX MOUNT. BLUE.
Notes:
* # 71125 Watertight Socket Locks onto France / Belgium Plug # 71341 # 71341. Prevents accidental disconnects.
* # 71125 Watertight Socket Locks onto Schuko Plug # 70341-N # 70341-N . Prevents accidental disconnects.
* France / Belgium Watertight extension cords available. View # 71015.
* Available in Color Dark Green. Part #71125-GRN
71130
FRANCE / BELGIUM LOCKING 16A-250V CEE 7/5 (FR1-16R) TYPE E IP66 / IP68 WATERTIGHT OUTLET (WITH GASKET), PANEL OR BOX MOUNT. BLUE.
Notes:
* # 71130 Watertight Socket Locks onto France / Belgium Plug # 71341. Prevents accidental disconnects.
* For surface mount applications use # 71325, 71320, 71322 wall boxes.
* France / Belgium Watertight extension cords available. View # 71015.
* Available in Color Dark Green. Part #71130-GRN
71125-GRN
FRANCE / BELGIUM LOCKING 16A-250V CEE 7/5 (FR1-16R) CEE 7/5 TYPE E IP66 / IP68 WATERTIGHT OUTLET (WITH GASKET), PANEL OR WALL BOX MOUNT. DARK GREEN.
Notes:
* # 71125-GRN Watertight Socket Locks onto France / Belgium Plug # 71341-GRN. Prevents accidental disconnects.
* France / Belgium Watertight extension cords available. View # 71015.
* Available in Color Blue. Part #71125
71130-GRN
FRANCE / BELGIUM LOCKING 16A-250V CEE 7/5 (FR1-16R) TYPE E IP66 / IP68 WATERTIGHT OUTLET (WITH GASKET), PANEL OR BOX MOUNT. DARK GREEN.
Notes:
* # 71130-GRN Watertight Socket Locks onto France / Belgium Plug # 71341-GRN. Prevents accidental disconnects.
* For surface mount applications use # 71325, 71320, 71322 wall boxes.
* France / Belgium Watertight extension cords available. View # 71015.
* Available in Color Blue. Part #71130
71110-WHT
FRANCE, BELGIUM CEE 7/5 TYPE E 16A-250V (FR1-16R) PANEL MOUNT OUTLET, SHUTTERED CONTACTS. WHITE.
Notes:
* Requires #97120-BZ wall plate when mounted on American 2x4 wall boxes.
* France, Belgium "locking" outlets #71125, #71130 available. Prevents accidental disconnects.
71120
FRANCE, BELGIUM 16A-250V WEATHERPROOF OUTLET (WITH GASKET), CEE 7/5 TYPE E (FR1-16R), (IP54 COVER CLOSED - IP20 COVER OPEN), PANEL OR WALL BOX MOUNT, "SHUTTERED CONTACTS". GRAY.
Notes:
* Mounts on American, European wall boxes or panel mount, DIN rail mount.
* Stainless steel wall plates #97120-BZ and #97120-DBZ mounts outlet onto American 2x4 and 4x4 wall boxes.
* France, Belgium "locking" outlets #71125, #71130 available. Prevents accidental disconnects.
74580-WP
AUSTRALIA / NEW ZEALAND 15A-250V PANEL MOUNT INLET (AU2-15P), WEATHERPROOF IP34. WHITE.
* For mobile equipment, RV, applications.
Notes:
* Panel mount inlet accepts Australia, New Zealand 20A, 15A, In-line connectors.
* For RV, camper, mobile home applications, Australia building wire available. # CNCP07AA002.
74120
AUSTRALIA / NEW ZEALAND 10A-250V PANEL MOUNT OUTLET TYPE I (AU1-10R), WEATHERPROOF IP44 RATED. WHITE.
Notes:
* For mobile equipment, RV applications.
* Australia TUV approved building wire/cable #CNCP07AA002.
* Outlet accepts 10 Ampere Australia / New Zealand plugs.
74180
AUSTRALIA / NEW ZEALAND 10A-250V PANEL MOUNT POWER INLET (AU1-10P). BLACK.
Notes:
* Panel mount inlet accepts Australia, New Zealand 20A, 15A, 10A In-line connectors.
74120-PFS
AUSTRALIA, NEW ZEALAND, CHINA 10A-250V WEATHERPROOF OUTLET TYPE I (AU1-10R), IP44 RATED, PANEL OR WALL BOX MOUNT. BLACK.
Notes:
* Stainless steel wall plates #97120-BZ and #97120-DBZ mounts outlet onto standard American 2x4 and 4x4 wall boxes.
* Not for use with #70125 wall box.
74520-A
AUSTRALIA / NEW ZEALAND 15A-250V / 10A-250V WEATHERPROOF PANEL OR WALL BOX MOUNT OUTLET TYPE I, AU2-15R, AU1-10R. BLACK.
Notes:
* Outlet accepts 15 Ampere & 10 Ampere Australia / New Zealand plugs.
* Stainless steel wall plates # 97120-BZ and # 97120-DBZ mounts outlet onto standard American 2x4 and 4x4 wall boxes.
* Not for use with # 70125 wall box.
72120-BLK
UNITED KINGDOM, UK, BRITISH 13A-250V IP54 WEATHERPROOF PANEL OR WALL BOX MOUNT OUTLET (UK1-13R), BS 1363A TYPE G SOCKET, SHUTTERED CONTACTS, 2 POLE-3 WIRE GROUNDING (2P+E). BLACK.
Notes:
* Stainless steel wall plates #97120-BZ and #97120-DBZ mounts outlet onto standard American 2X4 and 4X4 wall boxes.
* For surface mount applications use #70125 wall box.
* For DIN rail mount use #70125-DIN bracket with #70125 wall box.
75520-IT
ITALY, CHILE, EUROPEAN SCHUKO CEE 7/3 (EU1-16R) 16A-250V, 10A-250V CEI 23-50 (S11) CEI 23-16 TYPE L (IT1-10R) WEATHERPROOF PANEL OR WALL BOX MOUNT OUTLET. BLACK.
Notes:
* Accepts European Schuko type C, E, F, CEE 7, CEE 7/4, CEE 7/7 plugs, Europlug & Italy, Chile type L 10 Amp. plugs.
* Stainless steel wall plates #97120-BZ and #97120-DBZ mounts outlet onto standard American 2x4 and 4x4 wall boxes.
* Optional panel mount terminal shield #70127 available.
* Not for use with #70125 wall box.
75520
ITALY, CHILE 10/16A-250V CEI 23-50 (S17) (S11), CEI 23-16 TYPE L (IT1-10R/IT2-16R) IP44 WEATHERPROOF PANEL OR WALL BOX MOUNT OUTLET. BLUE.
Notes:
* Stainless steel wall plates #97120-BZ and #97120-DBZ mounts outlet onto standard American 2x4 and 4x4 wall boxes.
* For surface mount weatherproof applications use box #70125, weatherproof cover requires extra long stainless steel mounting screws. (extra long screws not included).
* For DIN rail mount use #70125-DIN bracket with #70125 wall box.
76120
SWISS 10A-250V WEATHERPROOF OUTLET IP54 (WITH GASKET) (SW1-10R) TYPE 13, PANEL OR WALL BOX MOUNT. GRAY.
Notes:
* Stainless steel wall plates #97120-BZ and #97120-DBZ mounts outlet onto standard American 2x4 and 4x4 wall boxes.
* For surface mount applications use #70125 wall box.
* For DIN rail mount use #70125-DIN bracket with #70125 wall box.
76120-NS
SWISS SN 441011, SEV 1011 10 AMPERE-250 VOLT WEATHERPROOF OUTLET WITH GASKET, IP55 RATED COVER CLOSED, IP20 COVER OPEN, PANEL OR WALL BOX MOUNT, TYPE T-13, 2 POLE-3 WIRE GROUNDING, BLACK WITH BLUE COVER.
Notes:
* Use plug 76140-SP with 76120-NS to maintain IP55 rating while in use.
* Stainless steel wall plates #97120-BZ, #97120-DBZ mounts outlet(s) onto standard American 2x4 and 4x4 wall boxes.
76520-NS
SWISS SN 441011, SEV 1011 16 AMPERE-250 VOLT WEATHERPROOF OUTLET WITH GASKET, IP55 RATED COVER CLOSED, IP20 COVER OPEN, PANEL OR WALL BOX MOUNT, TYPE T-23, 2 POLE-3 WIRE GROUNDING, BLACK WITH BLUE COVER.
Notes:
* Use 16 Amp plug 76540-SP with 76520-NS to maintain IP55 rating while in use.
* Stainless steel wall plates #97120-BZ, #97120-DBZ mounts outlet(s) onto standard American 2x4 and 4x4 wall boxes.
* 16 Amp outlet #76520-NS accepts 16A and 10A Swiss plugs.
78120
DENMARK, DANISH 16A-250V WEATHERPROOF (IP54 (DE1-13R) TYPE K OUTLET. GRAY.
Notes:
* Stainless steel wall plates #97120-BZ and #97120-DBZ mounts outlet onto standard American 2x4 and 4x4 wall boxes.
* For surface mount applications use #70125 wall box.
* For DIN rail mount use #70125-DIN bracket with #70125 wall box.
74900-WP
UNIVERSAL INTERNATIONAL, EUROPEAN, BRITISH, AUSTRALIA, ASIA, THAILAND MULTI-CONFIGURATION, 10A-250V WEATHERPROOF IP44 PANEL OR WALL BOX MOUNT POWER OUTLET, SHUTTERED CONTACTS, 2 POLE-3 WIRE GROUNDING (2P+E). BLACK.
Notes:
* Outlet accepts International European, British, Australia, American, South America, Asia, Thailand & Type D South Africa, India Plugs.
* Stainless steel wall plates # 97120-BZ and # 97120-DBZ mounts outlet onto standard American 2x4 and 4x4 wall boxes.
* Not for use with # 70125 wall box.
74720
CHINA 10A-250V WEATHERPROOF OUTLET WITH GASKET, (CH1-10R), PANEL OR WALL BOX MOUNT, IP44 RATED. BLACK.
Notes:
* Stainless steel wall plates #97120-BZ and #97120-DBZ mounts outlet onto standard American 2x4 and 4x4 wall boxes.
* Not for use with #70125 wall box.
85220
BRAZIL 10A-250V PANEL OR WALL BOX MOUNT OUTLET NBR 14136 TYPE N (BR2-10R), IP54 RATED. BLUE.
Notes:
* Stainless steel wall plates #97120-BZ and #97120-DBZ mounts outlet onto standard American 2x4 and 4x4 wall boxes.
* Not for use with #70125 wall box.
85220-BLK10
BRAZIL 10A-250V PANEL OR WALL BOX MOUNT OUTLET NBR 14136 TYPE N (BR2-10R), IP44 RATED. BLACK.
Notes:
* Stainless steel wall plates #97120-BZ and #97120-DBZ mounts outlet onto standard American 2x4 and 4x4 wall boxes.
* Not for use with #70125 wall box.
84270
ARGENTINA 10A-250V OUTLET (AR1-10R), IP54 RATED, PANEL OR WALL BOX MOUNT. BLUE.
Notes:
* Stainless steel wall plates #97120-BZ and #97120-DBZ mounts outlet onto standard American 2x4 and 4x4 wall boxes.
* For surface mount weatherproof applications use box #70125, weatherproof cover requires extra long stainless steel mounting screws. Extra long screws not included.
* For DIN rail mount use #70125-DIN bracket with #70125 wall box.
57011
IEC 60320 C-14 PANEL MOUNT INLET 15A-250V, 6.3 x 0.8 mm (0.250" x 0.032") Q.C. TERMINALS. BLACK.
57311
IEC 60320 C-14 15A-250V POWER INLET, SNAP-IN MOUNT, 6.3 x 0.8 mm (0.250" x 0.032") Q.C.TERMINALS. BLACK.
57710
IEC 60320 C-14 10A-250V PANEL MOUNT POWER INLET, SINGLE POLE (SPST) SWITCH, 4.8 x 0.8 mm (0.189” x 0.032”) TERMINALS. BLACK.
57720
IEC 60320 C-14 10A-250V SNAP-IN PANEL MOUNT POWER INLET, SINGLE POLE (SPST) SWITCH, 4.8 x 0.8 mm (0.189” x 0.032”) TERMINALS. BLACK.
57120
IEC 60320 C-13 POWER OUTLET, 15A/10A-250V, 6.3 x 0.8 mm (0.250" x 0.032") QUICK CONNECT TERMINALS. BLACK.
57320
IEC 60320, C-13 POWER OUTLET, 15/10A-250V, SNAP-IN MOUNT ON 1.5 mm THICK PANEL, 6.3 x 0.8 mm (0.250" x 0.032") TERMINALS. BLACK.
57320-LK
TRU-LOCK IEC 60320 LOCKING C-13 PANEL MOUNT OUTLET, UNIVERSAL APPROVALS, 15A-250V, 10A-250V, IMPACT RESISTANT NYLON (PA66), SNAP-IN MOUNT ON 1.5mm PANELS, 6.3 x 0.08mm (0.250 x 0.032"), QUICK CONNECT / SOLDER TERMINALS. BLACK.
Notes:
* Locking C13 receptacles designed to securely lock onto all C14 plugs, C14 power cords.
* IEC 60320 C-13 outlet locks onto IEC 60320 C-14 plugs. Red color button unlocks the C-14 plug.
* International approvals: C(RU)US, KEMA/KEUR, ENEC 05, CCC.
57350
IEC 60320 C-13/14 10A-250V SNAP-IN PANEL MOUNT POWER OUTLET/INLET, 4.8 x 0.8 mm (0.189" x 0.032") TERMINALS. BLACK.
57055-LK
TRU-LOCK IEC 60320, C-13 LOCKING CONNECTOR REWIREABLE, 15 AMP. 125V-250V, 10 AMP. 250 VOLT. BLACK.
Notes:
* Locking C13 connector designed to securely lock onto all C14 inlets, C14 plugs, C14 power cords.
* Max cable size = 9.0mm (0.354") dia.
* C-13 connector locks onto IEC 60320 C-14 inlets, PDU outlet strips, plugs, jumper cords. Red color release lever unlocks the C-13 connector.
* International approvals: C(UL)US, KEMA-KEUR, ENEC-05, PSE, AS/NZS 4417 RCM MARK, SGS
57055-NSL
IEC 60320 C-13 CONNECTOR, 15A-250V (UL/CSA), 10A-250V (VDE/CCC), ACCEPTS 14 AWG (2.5 mm2) CONDUCTORS, 10 mm (0.394") DIA. CORD, BLACK.
57055-NS
IEC 60320 C-13 CONNECTOR 15A-250V (UL/CSA), 10A-250V (VDE, CCC), ACCEPTS 18 AWG (1.0 mm2) CONDUCTORS, 8.5mm (0.335") DIA. CORDAGE, BLACK.
57030
IEC 60320 C-14 PLUG, 15A-250V, ACCEPTS 18 AWG (1.0 mm2) CONDUCTORS, 8.5 mm (0.335") DIA. CORDAGE. BLACK.
57030-NSL
IEC 60320 C-14 PLUG, 15A-250V (UL/CSA), 10A-250V (VDE, CCC), ACCEPTS 14 AWG (2.5 mm2) CONDUCTORS, 10 mm (0.394") DIA. CORDAGE, BLACK.
57080
IEC 60320 C-20 INLET, 20A-250V UL/CSA, 16A-250V VDE, SCREW TERMINALS. BLACK.
57081
IEC 60320 C-20 INLET, 20A-250V UL/CSA, 16A-250V VDE, 6.3 x 0.8 mm (0.250" x 0.032") Q.C. TABS. BLACK.
57745
IEC 60320 C-20 INLET, 20A-250V UL/CSA, 16A-250V VDE, SNAP-IN PANEL MOUNT, 6.3 x 0.8 mm (0.250" x 0.032") Q.D. TERMINALS. BLACK.
57730
IEC 60320 C-20 INLET, 20A-250V UL/CSA, 16A-250V VDE, ON/OFF SWITCH (DPST), PANEL MOUNT, 6.3 x 0.8 mm (0.250" x 0.032") Q.C. BLACK.
57735
IEC 60320 C-20 INLET, 20A-250V UL/CSA, 16A-250V VDE, ON/OFF SWITCH (DPST), SNAP-IN PANEL MOUNT, 6.3 x 0.8 mm (0.250" x 0.032") Q.D. BLACK.
57100-A
IEC 60320 C-19 OUTLET, 16A-250V, SCREW TERMINALS. BLACK.
57100
IEC 60320 C-19 OUTLET, 20A-250V UL/CSA, 16A-250V VDE, 6.3 x 0.8 mm (0.250 x 0.032") Q.C. TABS. BLACK.
57103
IEC 60320 C-19 OUTLET, SNAP-IN MOUNT, 21A-250V UL/CSA, 16A-250V VDE, 6.3 x 0.8 mm (0.250” x 0.032”) Q.D. TERMINALS. BLACK.
57103-LK
LOCKING IEC 60320 C-19 PANEL MOUNT POWER OUTLET, 16A-250V EUROPEAN APPROVED (ENEC 19, ASTA), 20A-250V C(RU)US (UL/CSA) APPROVED, SNAP-IN PANEL MOUNT. BLACK.
Notes:
* Locking C19 receptacles designed to securely lock onto all C20 plugs, C20 power cords.
57103-LKX1.0M
LOCKING IEC 60320 C-19 PANEL MOUNT POWER OUTLET, 16A-250V EUROPEAN APPROVED (ENEC 19, ASTA), 20A-250V C(RU)US (UL/CSA) APPROVED, SNAP-IN PANEL MOUNT. BLACK.
Notes:
* Locking C19 receptacles designed to securely lock onto all C20 plugs, C20 power cords.
57090-LK
TRU-LOCK IEC 60320, C-19 LOCKING CONNECTOR REWIREABLE, 20A-250V UL/CSA Rated, 16A-250V Europe/Australia rated, 2 POLE-3 WIRE GROUNDING (2P+E). BLACK.
Notes:
* Locking C19 connector designed to securely lock onto C20 power inlets, C20 plugs, C20 cords.
* Terminals accept 2.50mm conductors. Maximum cable diameter = 11.3mm (0.445").
* Terminal screw torque = 0.4Nm, Strain relief screw torque = 0.3Nm.
* Body Material Nylon, PA, PC LSZH (Low Smoke Zero Halogen).
57090
IEC 60320 C-19 CONNECTOR, 21A-250V UL/CSA, 16A-250V VDE, ACCEPTS 8-10 mm (0.315-0.394") DIA. CORD, BLACK.
57090-A
IEC 60320 C-19 CONNECTOR, 20A-250V UL/CSA, 16A-250V VDE, ACCEPTS 8.5-10 mm (0.335-0.394") DIA. CORD, BLACK.
57090-LK
TRU-LOCK IEC 60320, C-19 LOCKING CONNECTOR REWIREABLE, 20A-250V UL/CSA Rated, 16A-250V Europe/Australia rated, 2 POLE-3 WIRE GROUNDING (2P+E). BLACK.
Notes:
* Locking C19 connector designed to securely lock onto C20 power inlets, C20 plugs, C20 cords.
* Terminals accept 2.50mm conductors. Maximum cable diameter = 11.3mm (0.445").
* Terminal screw torque = 0.4Nm, Strain relief screw torque = 0.3Nm.
* Body Material Nylon, PA, PC LSZH (Low Smoke Zero Halogen).
57110
IEC 60320 C-20 PLUG, 20A-250V (UL,CSA), 16A-250V (VDE, CCC, ENEC 10). ACCEPTS 8-10 mm (0.315-0.394") DIA. CORD. BLACK.
57110-V
IEC 60320 C-20 PLUG, 20A-250V, ACCEPTS 12 AWG (4.0 mm2) CONDUCTORS, 12 mm (0.472") DIA. CORD, BLACK.
